TracoPower TBLC 75-124 SMPSU 28 V DC 3.1 A 75 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 104.99 / piece)
€ 104.99
incl. VAT
14-day return policy included
Highlights & Details
AC/DC switching power supply, TBLC-Series
- Output 28 V DC / 3.1 A
- Power 75 W
- Screw terminal
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
3.1 A
- Output current (max.) - rounded
3.1 A
- Min. input voltage
85 V AC
- Dim
(L x W x H) 59.5 x 72 x 89.5 mm
- Output voltage (max.)
28 V DC
- Connection
Screw terminal
75 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
55 °C
- Operating temperature (min.)
-25 °C
- Weight
220 g
- Width
72 mm
- Height
89.5 mm
- Length
59.5 mm
- Type
TBLC 75-124
- Output current (min.)
0 mA
- Output voltage (min.)
24 V DC
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1554660 TracoPower TBLC 75-124 SMPSU 28 V DC 3.1 A 75 W
Datasheet 1554660 TracoPower TBLC 75-124 SMPSU 28 V DC 3.1 A 75 W
User & Safety Instructions
User & Safety Instructions 1554660 TracoPower TBLC 75-124 SMPSU 28 V DC 3.1 A 75 W
Warranty Terms
Warranty Terms 1554660 TracoPower TBLC 75-124 SMPSU 28 V DC 3.1 A 75 W
