TracoPower TMPW 25-124 SMPSU 24 V DC 1.04 A 25 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Multiple: 10
Total (€ 28.69 / piece)
€ 286.90
incl. VAT
14-day return policy included
Highlights & Details
AC/DC-Switching power supply, TMPW 25-Series
- Output 24 V DC / 1.04 A
- Power 25 W
- Solder pins
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
305 V AC
- Max. output current
1.04 A
- Output current (max.) - rounded
1.04 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 52.5 x 27.5 x 23.5 mm
- Output voltage (max.)
24 V DC
- Connection
Solder pins
25 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Operating temperature (min.)
-40 °C
- Weight
55 g
- Width
27.5 mm
- Height
23.5 mm
- Length
52.5 mm
- Type
TMPW 25-124
- Max. temperature
70 °C
- Min. temperature
-40 °C
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2355562 TracoPower TMPW 25-124 SMPSU 24 V DC 1.04 A 25 W
Datasheet 2355562 TracoPower TMPW 25-124 SMPSU 24 V DC 1.04 A 25 W
Warranty Terms
Warranty Terms 2355562 TracoPower TMPW 25-124 SMPSU 24 V DC 1.04 A 25 W
