TracoPower TXH 240-148 SMPSU 48 V DC 5 A 240 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 134.99 / piece)
€ 134.99
incl. VAT
Only 1 Piece(s) available
Highlights & Details
TracoPower TXH 240-148 SMPSU 48 V DC 5 A 240 W
- No fan
- Efficiency: 90% type.
- Compact U-angle casing
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
5 A
- Output current (max.) - rounded
5 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 177 x 106 x 35 mm
- Output voltage (max.)
48 V DC
- Connection
Screw terminal
240 W
- No. of outputs
1 x
- Type
closed
- Weight
580 g
- Type
Synchronised
- Width
106 mm
- Height
35 mm
- Length
177 mm
- Type
TXH 240-148
- MTBF
50000 h
- Connection
Screw terminals
- Input voltage
90 - 264 V AC
- Max. temperature
+70 °C
- Min. temperature
-10 °C
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2789850 TracoPower TXH 240-148 SMPSU 48 V DC 5 A 240 W
Datasheet 2789850 TracoPower TXH 240-148 SMPSU 48 V DC 5 A 240 W
User & Safety Instructions
User & Safety Instructions 2789850 TracoPower TXH 240-148 SMPSU 48 V DC 5 A 240 W
Warranty Terms
Warranty Terms 2789850 TracoPower TXH 240-148 SMPSU 48 V DC 5 A 240 W
Description
Highly efficient built-in power supply with wide-range input. The output voltage is set permanently. This prevents a possible change in the voltage through mechanical adjustment elements.
Features
- Current limitation/DC-surge protection>110%
- Remaining ripple<1 %.
- According to EN55011, Class B, EN55022 Class B and FCC, Part 15, Level B, EN61000-3-2/-1, cUL/UL/IEC/EN 60950-1, CB-report
- Operating temperature: -10 to +70 ºC (derating>50 °C
Hints
Delivery without cover.
