TracoPower TXLN 960-148 AC/DC PSU module (+ enclosure) 48 V DC 20 A 960 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Total (€ 365.55 / piece)
€
Highlights & Details
AC/DC PSU Components
- Output 48 V DC / 20 A
- Power 960 W
- Screw terminal
Technical specifications
- Product type
AC/DC PSU module (+ enclosure)
- Input voltage (max.)
264 V AC
- Max. output current
20 A
- Output current (max.) - rounded
20 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 275.0 x 125.0 x 63.0 mm
- Output voltage (max.)
48 V DC
- Connection
Screw terminal
960 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
50 °C
- Operating temperature (min.)
-20 °C
- Weight
2500 g
- Width
125.0 mm
- Height
63.0 mm
- Length
275.0 mm
- Type
TXLN 960-148
- MTBF
84100 h
- Output current (min.)
0 mA
- Output voltage (min.)
48 V DC
- PFC
Yes
