WAGO 2216-1304 Continuity 12 mm Push-in connector Blue 20 pc(s)

A blue, two-part electrical terminal block for securely connecting cables, with two parallel conductors.
Image similar
Product type
Continuity
Connection
Push-in connector
Cross section (flexible) (max.)
16 mm²
Cross section (inflexible) (max.)
25 mm²
Nominal current - rounded value
76 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Thu 3 Dec
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 20 pc(s))
Total (€ 5.50 / piece)
€ 109.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Continuity and earth conductor terminal; with printer series 2216

  • 2216-1304

Technical specifications

Product type

Continuity

Features

+ latchkey

+ CAGE CLAMP®

Connection

Push-in connector

Cross section (flexible) (min.)

0.50 mm²

Cross section (flexible) (max.)

16 mm²

Cross section (inflexible) (min.)

0.50 mm²

Cross section (inflexible) (max.)

25 mm²

AWG (min.)

20

AWG max.

4

Clamp width

12 mm

No. of rows

1

Pins per row

3

Number of pins

3

Factory colour

Blue

Nominal current

76 A

Nominal current - rounded value

76 A

Min. stripping length

18 mm

Stripping length (max.)

20 mm

Manufacturer part #

2216-1304

Content

20 pc(s)

Industrial packaging

Yes

Type

2216-1304

Dim

(W x H) 12 mm x 37.10 mm

Width

12 mm

Height

37.10 mm

Connector colour

Blue

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 1719240 WAGO 2216-1304 Continuity 12 mm Push-in connector Blue 20 pc(s)

User & Safety Instructions

User & Safety Instructions 1719240 WAGO 2216-1304 Continuity 12 mm Push-in connector Blue 20 pc(s)

Information

Information 1719240 WAGO 2216-1304 Continuity 12 mm Push-in connector Blue 20 pc(s)
