WAGO 250-504/000-006 Spring-loaded terminal 1.00 mm² Number of pins 4 Blue 220 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number (Package size 220 pc(s))
Total (€ 1.13 / piece)
€
Technical specifications
- KL-LEISTE EINLöTBAR 4-POLIG
- Features
+ CAGE CLAMP®
- CS
5 mm
- No. of rows
1
- Pins per row
4
- Number of pins
4
- Series
250
- Min. stripping length
10 mm
- Stripping length (max.)
10 mm
- Connection
Spring-loaded terminal
Print
- Cross section (flexible) (min.)
0.50 mm²
- Nominal current - rounded value
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
1.00 mm²
- Cross section (inflexible) (max.)
1.50 mm²
- AWG (min.)
20
- Connector orientation
At an angle (to the PCB)
- AWG max.
16
- Contact material
Cathode copper, tin plated
- Factory colour
Blue
- Wire protection
Yes
- Content
220 pc(s)
- Height
20.50 mm
- Length
13.00 mm
- Width
21.50 mm
- Industrial packaging
Yes
- Manufacturer part #
250-504/000-006
- Type
250-504/000-006
- Nominal voltage
320 V
- Product type
Spring-loaded terminal
Documents & Downloads
Datasheet
Datasheet 745434 WAGO 250-504/000-006 Spring-loaded terminal 1.00 mm² Number of pins 4 Blue 220 pc(s)
User & Safety Instructions
User & Safety Instructions 745434 WAGO 250-504/000-006 Spring-loaded terminal 1.00 mm² Number of pins 4 Blue 220 pc(s)
