Name: WAGO 264-290 Punch-down block 10 mm Pull spring Configuration: L Grey 25 pc(s) Package
Brand: WAGO
SKU: 535013
Availability: BackOrder

A white, rectangular plastic block with multiple square openings on the top surface, potentially for technical applications.

Technical drawing of a plug connection with dimensions: 32 mm width, 15.8 mm height, 22.1 mm length. Contains calculation formula.

1/2

Packaging type

Package

Product type

Punch-down block

Connection

Pull spring

Cross section (flexible) (max.)

2.50 mm²

Cross section (inflexible) (max.)

2.50 mm²

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Mon 16 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 25 pc(s))

Set(s)

Total (€ 15.40 / piece)

€ 385.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

4-conductor Ex e II terminal strip

264-290
Industrial packaging, pack of 25

Technical specifications

4 COND.EX T.BL.STR.W.FX.FLANGE 10POL

Packaging type: Package

Product type: Punch-down block

Features: + latch lock base
Complies with ATEX Ex-e II standards

Connection: Pull spring

Configuration: L

Cross section (flexible) (min.): 0.50 mm²

Cross section (flexible) (max.): 2.50 mm²

Cross section (inflexible) (min.): 0.50 mm²

Cross section (inflexible) (max.): 2.50 mm²

AWG (min.): 20

AWG max.: 14

Clamp width: 10 mm

No. of rows: 10

Pins per row: 4

Number of pins: 40

Factory colour: Grey

Nominal current: 23 A

Nominal current - rounded value: 23 A

Nominal voltage: 690 V

Min. stripping length: 8 mm

Stripping length (max.): 9 mm

Manufacturer part #: 264-290

Content: 25 pc(s)

Industrial packaging: Yes

Type: 264-290

Dim: (W x H) 107 mm x 22.10 mm

Width: 107 mm

Height: 22.10 mm

Connector colour: Grey

UKCA: not relevant

Variants(All information include VAT, plus shipping costs)

Content

Cross section (flexible) (min.)

Cross section (inflexible) (min.)

Nominal current - rounded value

WAGO 264-202 Punch-down block 10 mm Pull spring Configuration: L Grey 100 pc(s)

Item no:534932

Dispatches on Mon 16 Nov

Conrad Electronic

100 pc(s)

0.08 mm²

24 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 339.00^*

WAGO 264-203 Punch-down block 10 mm Pull spring Configuration: L Grey 100 pc(s) Package

Item no:534935

Dispatches on Mon 16 Nov

Conrad Electronic

100 pc(s)

0.08 mm²

24 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 485.00^*

WAGO 264-204 Punch-down block 10 mm Pull spring Configuration: L Grey 100 pc(s) Piece

Item no:534937

Dispatches on Mon 16 Nov

Conrad Electronic

100 pc(s)

0.08 mm²

24 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 625.00^*

WAGO 264-208 Punch-down block 10 mm Pull spring Configuration: L Grey 100 pc(s)

Item no:546772

Dispatches on Mon 16 Nov

Conrad Electronic

100 pc(s)

0.08 mm²

24 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1,189.00^*

WAGO 264-209 Punch-down block 10 mm Pull spring Configuration: L Grey 50 pc(s) Package

Item no:534941

Dispatches on Mon 16 Nov

Conrad Electronic

50 pc(s)

0.08 mm²

24 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 669.00^*

WAGO 264-211 Punch-down block 10 mm Pull spring Configuration: L Grey 25 pc(s) Piece

Item no:534942

Dispatches on Mon 16 Nov

Conrad Electronic

25 pc(s)

0.08 mm²

24 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 405.00^*

WAGO 264-212 Punch-down block 10 mm Pull spring Configuration: L Grey 25 pc(s) Package

Item no:534943

Dispatches on Mon 16 Nov

Conrad Electronic

25 pc(s)

0.08 mm²

24 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 439.00^*

WAGO 264-232 Punch-down block 10 mm Pull spring Configuration: L Grey 100 pc(s) Package

Item no:534955

Dispatches on Mon 16 Nov

Conrad Electronic

100 pc(s)

0.50 mm²

23 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 355.00^*

WAGO 264-233 Punch-down block 10 mm Pull spring Configuration: L Grey 100 pc(s) Package

Item no:534956

Dispatches on Mon 16 Nov

Conrad Electronic

100 pc(s)

0.50 mm²

23 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 495.00^*

WAGO 264-234 Punch-down block 10 mm Pull spring Configuration: L Grey 100 pc(s) Piece

Item no:534957

Dispatches on Mon 16 Nov

Conrad Electronic

100 pc(s)

0.50 mm²

23 A

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 645.00^*

Documents & Downloads

Datasheet

Datasheet 535013 WAGO 264-290 Punch-down block 10 mm Pull spring Configuration: L Grey 25 pc(s) Package

User & Safety Instructions

User & Safety Instructions 535013 WAGO 264-290 Punch-down block 10 mm Pull spring Configuration: L Grey 25 pc(s) Package

Description

With snap in bases, for plate thickness 0409 14.2 mm, mounting hole Ø 3.5 mm, even on aluminum rail 210-154 or 209-120 with mounting base on TS 35, complies with ATEX Ex-e II, 10-pin, light gray.
