WAGO 280-104 Continuity 5 mm Pull spring Configuration: N Blue 100 pc(s) Piece

Grey electrical terminal block for DIN rail mounting, with side input slots and metal connections in the centre.
Packaging type
Piece
Product type
Continuity
Connection
Pull spring
Cross section (flexible) (max.)
2.50 mm²
Cross section (inflexible) (max.)
2.50 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Mon 7 Dec
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 100 pc(s))
Total (€ 1.40 / piece)
€ 139.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

2-conductor through terminal block

  • 280-104
  • Industrial packaging with 100 pieces

Technical specifications

  • THROUGH TERM.BL. 2.5 SQMM BLUE
Packaging type

Piece

Product type

Continuity

Features

Complies with ATEX Ex I standards

Connection

Pull spring

Configuration

N

Cross section (flexible) (min.)

0.08 mm²

Cross section (flexible) (max.)

2.50 mm²

Cross section (inflexible) (min.)

0.08 mm²

Cross section (inflexible) (max.)

2.50 mm²

AWG (min.)

28

AWG max.

14

Clamp width

5 mm

No. of rows

1

Pins per row

2

Number of pins

2

Factory colour

Blue

Nominal current

24 A

Nominal current - rounded value

24 A

Nominal voltage

800 V

Min. stripping length

8 mm

Stripping length (max.)

9 mm

Manufacturer part #

280-104

Content

100 pc(s)

Industrial packaging

Yes

Type

280-104

Dim

(W x H) 5 mm x 30.50 mm

Width

5 mm

Height

30.50 mm

Contamination level

3

Connector colour

Blue

DIN rail (top hat rail) 35 mm

Blue

5

42.5 mm

30.5 mm

800 V

105-105 °C

V0

TRUE

Spring clamp connection

Spring clamp connection

1

2

FALSE

0.08-2.5 mm²

0.08-2.5 mm²

0.08-2.5 mm²

Thermoplastic

24 A

TRUE

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 535458 WAGO 280-104 Continuity 5 mm Pull spring Configuration: N Blue 100 pc(s) Piece

User & Safety Instructions

User & Safety Instructions 535458 WAGO 280-104 Continuity 5 mm Pull spring Configuration: N Blue 100 pc(s) Piece

Description

Complies with ATEX Ex i, blue.

This text is machine translated.
