Connectors & CablesConnectorsTerminal BlocksSerial Terminals

WAGO 280-548 Triple port continuity 5 mm Pull spring White, Grey 40 pc(s) Package

A multi-stage, grey terminal block socket with multiple connection points, lever, and mounting rail, commonly used in electrical engineering.
Cross-section of a three-stage terminal block with dimensions: width 103 mm (4.05 inches), height 76.5 mm (3.01 inches).
1/2
Packaging type
Package
Product type
Triple port continuity
Connection
Pull spring
Cross section (flexible) (max.)
2.50 mm²
Cross section (inflexible) (max.)
2.50 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Tue 24 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 40 pc(s))
Total (€ 9.63 / piece)
€ 385.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Triple-deck terminal block

  • 280-548

Technical specifications

  • TRIPLE DECK TERM.BL.WHITE/GREY/GREY
Packaging type

Package

Product type

Triple port continuity

Connection

Pull spring

Cross section (flexible) (min.)

0.08 mm²

Cross section (flexible) (max.)

2.50 mm²

Cross section (inflexible) (min.)

0.08 mm²

Cross section (inflexible) (max.)

2.50 mm²

AWG (min.)

28

AWG max.

14

Clamp width

5 mm

No. of rows

3

Pins per row

2

Number of pins

6

Factory colour

White

Grey

Nominal current

20 A

Nominal current - rounded value

20 A

Nominal voltage

500 V

Min. stripping length

8 mm

Stripping length (max.)

9 mm

Manufacturer part #

280-548

Content

40 pc(s)

Industrial packaging

Yes

Type

280-548

Dim

(L x W x H) 5 x 5 x 76.50 mm

Width

5 mm

Height

76.50 mm

Length

5 mm

Connector colour

White

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 535811 WAGO 280-548 Triple port continuity 5 mm Pull spring White, Grey 40 pc(s) Package

User & Safety Instructions

User & Safety Instructions 535811 WAGO 280-548 Triple port continuity 5 mm Pull spring White, Grey 40 pc(s) Package

Description

Shield conductor/continuity/through terminal, white/gray/gray.
