Name: Axing SSD 5-10 Antenna socket TV, FM, SAT Flush mount Non-terminated
Brand: Axing
SKU: 942335
Availability: InStock

'AXING SSD 5-14 Coaxial Socket', silver housing with multiple connections, suitable for TV and radio signals.

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

60 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 13.99 / piece)

€ 16.99

-18 %

€ 13.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Axing SSD 5-10 SAT transmission socket

Frequency range 5 - 2200 MHz
Reverse channel-compatible 5 - 65 MHz.
Attenuation 10 dB

Technical specifications

Type: Non-terminated

Product type: Antenna socket

Suitable for: TV
FM
SAT

Mounting type: Flush mount

Frequency range: 5 -2200 MHz

Dim: (W x H) 68 mm x 68 mm

Suitable for class A: Yes

Reverse channel: 5 - 65 MHz

DC outlet: Yes

Width: 68 mm

Height: 68 mm

Design type: Gateway socket

Attenuation: 10 dB

Weight: 0.125

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 942335 Axing SSD 5-10 Antenna socket TV, FM, SAT Flush mount Non-terminated

User & Safety Instructions

User & Safety Instructions 942335 Axing SSD 5-10 Antenna socket TV, FM, SAT Flush mount Non-terminated

Information

Information 942335 Axing SSD 5-10 Antenna socket TV, FM, SAT Flush mount Non-terminated

Description

Multi-functional socket: SAT, BK and UNICABLE single-cable multi-switch antenna socket, via the IEC connections BK, terr., and radio signals can be received. In nickel-plated and highly shielded housing. Suitable for the frames and cover plates complying with the German standard (80 x 80 mm) of all well-known German switch material manufacturers.

Features

Class A serviceable
Multipurpose Antenna socket for CATV, SAT and Unicable systems in accordance with EN 50494
Diode linked SAT connection
Expanded F socket (installation friendly)
New improved cable entry
Suitable for all usual switching programs (dt. standard).
Transmission sockets with low transmission loss suitable for Busch-Jaeger, Merten, Kopp, etc. Suitable cable of 0.63 - 1.13 mm inner conductor / 4.70 - 7.35 mm outer diameter
