B-SAFETY BR564230 LED escape route lighting Wall surface-mount Exit, Emergency exit, Right, Left
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 58.82 / piece)
€ 83.18
-29 %
€ 58.82
plus VAT.
Highlights & Details
LED escape route lighting B-SAFETY V-LUX STANDARD BR564230 (Wall surface-mount)
- 3 h emergency operation
- AUTOTEST
- Ceiling mounting
Technical specifications
- Color: RAL 9003 (white)
- NI-CD rechargeable battery 3.6 V / 1500 mAh
- Dim
(L x W x H) 365 x 352 x 110 mm
- Product type
LED escape route lighting
- Main battery supply
No
- Motif
Exit, RH arrow pointing E
Exit left
- Max. battery life
3 h
- Type
Exit
Emergency exit
Right
Left
- Type
Self-adhesive film (permanent)
- Backlit
Yes
- Operating voltage
230 V
- Detection range
20 m
- Weight
0.97 kg
5.5 W
- Material
Polycarbonate (PC)
- Mounting type
Wall surface-mount
- Width
352 mm
- Height
110 mm
- Depth
64 mm
IP65
- Length
365 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2357092 B-SAFETY BR564230 LED escape route lighting Wall surface-mount Exit, Emergency exit, Right, Left
User & Safety Instructions
User & Safety Instructions 2357092 B-SAFETY BR564230 LED escape route lighting Wall surface-mount Exit, Emergency exit, Right, Left
Description
Safety lamp and rescue sign lamp in IP 65 in standard design. With AUTOTEST test function, signaling via 1x multi-colored LED, including test button. Can be switched from continuous to standby mode. Inclusive of 1x standard set of information signs (emergency exit, rescue path right, rescue path left) according to DIN EN ISO 7010 as self-adhesive PVC-foils. Assembly of pictograms on the cover.
Product features:
· Automatic test function AUTOTEST, signaling via 1x multi-colored LED, including test button
· can be switched from continuous to standby mode
· including 1x standard set information signs (emergency exit, emergency exit right, emergency exit left, emergency exit straight ahead) according to DIN EN ISO 7010
· Installation of pictograms on the polycarbonate cover (PVC film, self-adhesive)
· including white reflector for good light distribution
· Vandal-proof due to very impact-resistant polycarbonate housing
· Use in meeting facilities, universities, football stadiums, office buildings, shops, Banks, shopping centers, swimming pools, schools and hospitals
· IN ACCORDANCE WITH DIN EN 60598-2-22, EN 1838, EN 62034 AND DIN VDE 0108
This text is machine translated.
Product features:
· Automatic test function AUTOTEST, signaling via 1x multi-colored LED, including test button
· can be switched from continuous to standby mode
· including 1x standard set information signs (emergency exit, emergency exit right, emergency exit left, emergency exit straight ahead) according to DIN EN ISO 7010
· Installation of pictograms on the polycarbonate cover (PVC film, self-adhesive)
· including white reflector for good light distribution
· Vandal-proof due to very impact-resistant polycarbonate housing
· Use in meeting facilities, universities, football stadiums, office buildings, shops, Banks, shopping centers, swimming pools, schools and hospitals
· IN ACCORDANCE WITH DIN EN 60598-2-22, EN 1838, EN 62034 AND DIN VDE 0108
This text is machine translated.
Scope of delivery
- Incl. standard set information signs (emergency exit, RW left, RW right, RW straight off)
