Name: B-SAFETY BR 558 030 Escape route lighting Wall surface-mount
Brand: B-SAFETY
SKU: 558477
Availability: InStock

Green emergency exit sign with a pictogram of a running person and an arrow pointing downwards, mounted on a grey wall.

Green emergency exit sign with a pictogram of a person running to the right and an arrow pointing downwards.

Emergency exit sign: Green pictogram of a person running left through a door, accompanied by an arrow pointing in the same direction.

'Evacuation sign showing a figure running through a door with an arrow pointing to the right.'

1/4

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Wed 11 Nov

16 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 104.99 / piece)

€ 170.00

-38 %

€ 104.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Escape route lighting B-SAFETY L-Lux Standard BR 558 030 (Wall surface-mount)

Protection type IP40
Auto-test function
Rechargeable battery with an operation duration of 3 hours.

Technical specifications

Dim: (W x H x D) 274 x 195 x 44 mm

Product type: Escape route lighting

Main battery supply: No

Max. battery life: 3 h

Operating voltage: 230 V AC

EN standard: EN 60598-1:2015
EN 60598-2-22:2014
EN 55015:2013
EN 61347-1:2015
EN 61347-2-13:2014
EN 61347-2-7:2012
EN 62034:2012
EN 61547:2009
EN 61000-3-3:2013
EN 61000-3-2.2014

Weight: 1100 g

: 5.2 W

Material: Aluminium
Polycarbonate (PC)

Mounting type: Wall surface-mount

Width: 274 mm

Height: 195 mm

Depth: 44 mm

: IP40

Protection class: I

Documents & Downloads

Datasheet

Datasheet 558477 B-SAFETY BR 558 030 Escape route lighting Wall surface-mount

User & Safety Instructions

User & Safety Instructions 558477 B-SAFETY BR 558 030 Escape route lighting Wall surface-mount

Conformity certificate

Conformity certificate 558477 B-SAFETY BR 558 030 Escape route lighting Wall surface-mount

Description

Exclusive LED-disc light in modern design, for application in offices, public buildings, administrative buildings, schools and hotels. As a single battery discs-emergency light with auto-test function, signalling via 1 x multi-colored LED, including test button, according to DIN EN 60598-1, DIN EN 60598-2-22 and DIN EN 1838 for systems in accordance with DIN VDE 0108/10.89 to separate operation.

This text is machine translated.

Features

Continuous and standby switching
Permissible ambient temperature: 5 - 35°C
Lamps including 24x LED
NI-MH rechargeable battery 4.8 V/800 mAh
Instructions: According to DIN ISO 7010

Scope of delivery

Emergency light incl. plexiglas window
Standard set of information signs (TYPE A = emergency exit, TYPE B = escape route to the right, TYPE C = escape route left)
User manual.

Description

Features

Continuous and standby switching
Permissible ambient temperature: 5 - 35°C
Lamps including 24x LED
NI-MH rechargeable battery 4.8 V/800 mAh
Instructions: According to DIN ISO 7010

Scope of delivery

Emergency light incl. plexiglas window
Standard set of information signs (TYPE A = emergency exit, TYPE B = escape route to the right, TYPE C = escape route left)
User manual.
