B-SAFETY BR530030 LED escape route lighting Ceiling surface-mount, Wall surface-mount Exit, Emergency exit, Right, Left
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 117.64 / piece)
€ 117.64
plus VAT.
Only 9 Piece(s) available
Highlights & Details
LED escape route lighting B-SAFETY E-LUX STANDARD BR530030 (Ceiling surface-mount, Wall surface-mount)
- AUTOTEST
- 3 h emergency operation
- Universal mounting wall and ceiling
Technical specifications
- Color: RAL 9003 (white)
- NI-MH rechargeable battery 4.8 V / 600 mAh
- Dim
(L x W x H) 380 x 301 x 182 mm
- Product type
LED escape route lighting
- Main battery supply
No
- Motif
Exit, RH arrow pointing E
Exit left
- Max. battery life
3 h
- Type
Exit
Emergency exit
Right
Left
- Type
Self-adhesive film (permanent)
- Backlit
Yes
- Operating voltage
230 V
- Detection range
22 m
- Weight
0.73 kg
1.5 W
- Material
Polycarbonate (PC)
- Mounting type
Ceiling surface-mount
Wall surface-mount
- Width
301 mm
- Height
182 mm
- Depth
43 mm
IP40
- Length
380 mm
Documents & Downloads
Datasheet
Datasheet 2357090 B-SAFETY BR530030 LED escape route lighting Ceiling surface-mount, Wall surface-mount Exit, Emergency exit, Right, Left
User & Safety Instructions
User & Safety Instructions 2357090 B-SAFETY BR530030 LED escape route lighting Ceiling surface-mount, Wall surface-mount Exit, Emergency exit, Right, Left
Description
Energy-saving and universally usable LED-rescue lamp with quick mounting system in protection class II, as single battery emergency lamp with AUTOTEST-function, signaling via status LED, including test button, according to DIN EN 60598-1, DIN EN 60598-2-22, DIN EN 62034 and DIN EN 1838 for systems according to DIN VDE 0108, for separate operation.
Product features:
· Automatic test function AUTOTEST, signaling via 3x colored LED, including test button
· Continuous switching
· including 1x standard set information signs (emergency exit, emergency exit right, emergency exit left, emergency exit straight ahead) according to DIN EN ISO 7010
· Installation of pictograms on the polycarbonate cover (PET film, self-adhesive)
· Quick mounting of the lamp by "click-mounting system"
· tested LED life of at least 50,000 hours (SMD-LED´s)
· High-temperature NI-MH BATTERY for long life
· Use in meeting facilities, universities, office buildings, shops, banks, Shopping centers, schools and hospitals
· IN ACCORDANCE WITH DIN EN 60598-2-22, EN 1838, EN 62034 AND DIN VDE 0108
This text is machine translated.
Product features:
· Automatic test function AUTOTEST, signaling via 3x colored LED, including test button
· Continuous switching
· including 1x standard set information signs (emergency exit, emergency exit right, emergency exit left, emergency exit straight ahead) according to DIN EN ISO 7010
· Installation of pictograms on the polycarbonate cover (PET film, self-adhesive)
· Quick mounting of the lamp by "click-mounting system"
· tested LED life of at least 50,000 hours (SMD-LED´s)
· High-temperature NI-MH BATTERY for long life
· Use in meeting facilities, universities, office buildings, shops, banks, Shopping centers, schools and hospitals
· IN ACCORDANCE WITH DIN EN 60598-2-22, EN 1838, EN 62034 AND DIN VDE 0108
This text is machine translated.
Scope of delivery
- Incl. standard set information signs (emergency exit, RW left, RW right, RW straight ahead
