Buy Chamberlain RPD25-05 Tubular motor 60 mm 50 kg 191 W 25 Nm

Packaging of a blue tubular motor by Chamberlain, featuring an illustration of the motor and an image of a person in the background.

Long, blue cylindrical motor with black mounting. Used for roller shutter or awning drives.

Packaging for an electric roller shutter motor by Chamberlain, suitable for roller shutters up to 11 m². Image of a smiling couple in front of a window.

Two-storey modern detached house with light-coloured render and large windows, surrounded by a well-maintained garden and blue sky in the background.

1/4

Fast track dispatch on Fri, 11 Sep

2 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 65.54 / piece)

€ 65.54

plus VAT.

Only 2 Piece(s) available

Report legal concerns

Highlights & Details

Tubular motor Chamberlain RPD25-05 25 Nm

Suitable for the installation of new buildings and for the modernization
Can be used for every conventional shutters
Incl. adapter, driver and journals

Technical specifications

End-switch range (U): 25 U
Max. Shutter surface (PVC): 11 m²
Max. Shutter surface (aluminum): 9 m²
Max. Shutter surface (wood): 5 m²
Maximum Operating Time: 4 min

Product type: Tubular motor

Suitable for shutter axle Ø: 60 mm

Motor power: 191 W

Dim: (Ø x H) 40 mm x 45 mm

Weight: 2.31 kg

Rotational speed: 15 U/min

Length: 583 mm

Tensile force (max.): 50 kg

Max. current consumption: 0.83 A

Operating voltage: 230 V

Width: 45 mm

Height: 45 mm

(Ø): 40 mm

Hub: Not required

Torque: 25 Nm

Lead length: 190 cm

Factory colour: Blue

Power consumption: 235 W

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1547055 Chamberlain RPD25-05 Tubular motor 60 mm 50 kg 191 W 25 Nm

Description

Shutter drive with a pulling force of 25 Nm suitable for octagonal shafts with a diameter of 60 mm. The Chamberlain shutter drive rpd 25 open shutters with an area of up to 11 m² (PVC) with a maximum weight of 50 kg. For a relaxing installation are essential components such as Adapter, shaft and bearing pins pre-assembled. The setting of the end points can be easily and quickly with the help of the enclosed adjustment pin can be made. The adapter for the hexagonal shaft is included in the delivery.
