D-Link DES-1008C/E DES-1008C/E Network RJ45 switch 1.6 GBit/s
EAN:
Part number:
Item no:
Number
Total (€ 13.44 / piece)
€ 13.44
plus VAT.
D-Link 0 unmanaged fast Ethernet (10/100) desktop white
Highlights & Details
- Offers 8 100Base-TX ports for versatile connectivity
- Plug and Play design for easy installation
- Optimized performance with 1.6 Gbps switching fabric bandwidth
- Supports Jumbo frames with up to 2048 bytes
- Works effectively over a wide temperature range
Technical specifications
- Power source: Direct current
- Product type
Network RJ45 switch
- Transfer rate
1.6 GBit/s
- Working principle
Unmanaged switch
- Ethernet ports
8
- Jumbo frames
Yes
- MAC addresses
2000
- Weight
74.8 g
- Width
131 mm
- Height
21 mm
- Depth
54 mm
- Type
DES-1008C/E
- Factory colour
White
- Case type
Desktop
- UKCA
not relevant
- Fanless
yes
- Operating temperature (T-T)
0 - 40 °C
- Basic switching RJ-45 Ethernet ports quantity
8
- Packet buffer memory
0.093 MB
- Storage relative humidity (H-H)
5 - 95 %
- Auto-negotiation
yes
- Switching capacity
1.6 Gbit/s
- Heat dissipation
0.691 BTU/h
- Packet forwarding rate (10 Mbps)
14880 pps
- Packet forwarding rate (100 Mbps)
148800 pps
- Flow control support
yes
- Power over Ethernet (PoE)
no
- Stackable
no
- Jumbo frames support
yes
- Store-and-forward
yes
- Rack mounting
no
- Mean time between failures (MTBF)
1579582 h
- Full duplex
yes
- MAC address table
2000 Eintragungen
- Auto MDI/MDI-X
yes
- Operating relative humidity (H-H)
10 - 90 %
- 10G support
no
- Storage temperature (T-T)
-40 - 70 °C
- Forwarding rate
1.19 Mpps
- Power consumption (max)
1.55 W
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3763537 D-Link DES-1008C/E DES-1008C/E Network RJ45 switch 1.6 GBit/s
Description
The D-Link DES-1008C 8-port Fast Ethernet Unmanaged Switch is a compact, cost-effective network solution for home offices, SOHO applications and small businesses that need a reliable wired network connection without complicated setup.
With eight 10/100 Mbit/s Fast-Ethernet-ports the DES-1008C enables a simple expansion of your network and the connection of several devices such as PCs, printers, IP cameras or routers. Thanks to the plug-and-play design no technical configuration is required – connect and start immediately.
All ports have Auto MDI/MDIX, where the switch automatically adapts to straight or crossover cables. IEEE 802.3x flow control and the secure store and forward switching process ensure efficient data processing, reduced network overload and stable performance.
The DES-1008C automatically detects inactive network connections and puts unused ports in standby mode in order to reduce the power consumption. The fan-less, compact desktop-design ensures a low-noise operation and flexible positioning in every work environment.
This text is machine translated.
With eight 10/100 Mbit/s Fast-Ethernet-ports the DES-1008C enables a simple expansion of your network and the connection of several devices such as PCs, printers, IP cameras or routers. Thanks to the plug-and-play design no technical configuration is required – connect and start immediately.
All ports have Auto MDI/MDIX, where the switch automatically adapts to straight or crossover cables. IEEE 802.3x flow control and the secure store and forward switching process ensure efficient data processing, reduced network overload and stable performance.
The DES-1008C automatically detects inactive network connections and puts unused ports in standby mode in order to reduce the power consumption. The fan-less, compact desktop-design ensures a low-noise operation and flexible positioning in every work environment.
This text is machine translated.
Scope of delivery
- 8-Port Fast Ethernet Unmanaged Switch (DES-1008C), quick installation guide, power supply
