Name: D-Link DMS-1250-12/E DMS-1250-12/E Network SFP+ switch
Brand: D-Link
SKU: 3466355
Availability: SoldOut

A black D-Link network switch with twelve Ethernet ports and two SFP ports on the front panel, used for connecting multiple devices in a network.

D-Link network switch with 11 ports, including ethernet and uplink connections, and LED status indicators on the front panel.

A D-Link network switch with multiple Ethernet ports and LED indicators, used for managing and routing data in a network setup.

A rectangular black electronic device with a power input socket and a ventilation grille on the rear panel.

1/4

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 399.00 / piece)

€ 399.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

D-Link DMS-1250-12/E Network switch Managed L2 10G Ethernet (100/1000/10000) black

Managed L2 Web-based management
Quality of Service (QoS) Support Site Settings Configuration (CLI)
Number of basic switching RJ-45 Ethernet ports: 10
MAC address table: 16000 entries Routing/switching capacity: 120 Gb/s.
Access control list
Rack mounting Stackable
AC power supply included

Technical specifications

Number of fans: 1 fans
Energy source: AC

Product type: Network SFP+ switch

LAN transfer rate: 10 MBit/s
100 MBit/s
1000 MBit/s
2500 MBit/s

Working principle: Managed switch

Ethernet ports: 8

SFP+ ports: 2 x

SFP ports: 2 x

No. of 100 Mbps/1Gbps/10Gbps ports: 2 x

Port type: 8 x 10/100/1000/2.5G + 2 x 10 Gigabit Ethernet + 2 x 10 Gigabit SFP+

Auto-uplink at each port: Yes

Jumbo frames: Yes

Power supply (LOV): mains-powered

MAC addresses: 16000

Weight: 2.58 kg

Width: 440 mm

Height: 44 mm

Depth: 210 mm

Type: DMS-1250-12/E

Factory colour: Black

Max. ambient temperature: -5 °C

Min. ambient temperature: 50 °C

Power supply (details): 100 - 240 V

: 512 MB

UKCA: yes

Fanless: yes

Operating temperature (T-T): -5 - 50 °C

Basic switching RJ-45 Ethernet ports quantity: 10

Packet buffer memory: 12 MB

Storage relative humidity (H-H): 0 - 95 %

Password protection: yes

Switching capacity: 120 Gbit/s

Traffic classification: yes

Loop protection: yes

ARP inspection: yes

Jumbo frames: 12000

Active link detection: yes

SFP+ module slots quantity: 2

Flow control support: yes

Power over Ethernet (PoE): no

MAC address filtering: yes

Quality of Service (QoS) support: yes

Port mirroring: yes

Link aggregation: yes

Stackable: yes

Jumbo frames support: yes

Multicast support: yes

Broadcast storm control: yes

Configuring Location Settings (CLI): yes

Web-based management: yes

Store-and-forward: yes

Access Control List (ACL): yes

Rate limiting: yes

2.5G Ethernet (copper) ports quantity: 8

10G Ethernet (copper) ports quantity: 2

Rack mounting: yes

Flash memory: 32 MB

MAC address table: 16000 Eintragungen

IGMP snooping: yes

Auto MDI/MDI-X: yes

Number of VLANs: 4096

Spanning tree protocol: yes

Operating relative humidity (H-H): 0 - 95 %

VLAN support: yes

Storage temperature (T-T): -20 - 70 °C

Forwarding rate: 89.29 Mpps

Power consumption (max): 23.023 W

Power supply included: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3466355 D-Link DMS-1250-12/E DMS-1250-12/E Network SFP+ switch

Description

The D-Link DMS 1250-12 switch offers features to improve network performance and management in various environments. With a switching capacity of 120 Gbps and a packet forwarding rate of 89.29 Mpps, this switch ensures efficient computing and supports up to 128 IGMP groups and 4094 VLAN groups. The device's capacity for a packet buffer size of 12 Mbit and versatile interface options, including eight 10/100/1000/2.5G ports and two additional 10GBASE-T ports, provide flexibility for different network requirements.
The D-Link DMS 1250-12 is designed for a wide range of operating conditions, supports temperatures from -5 °C to 50 °C and also remains functional at humidity of up to 95%. The switch is equipped with security features such as port security entries and access control lists that ensure network security. A number of remote management protocols improve user experience and control and monitor network performance.

This text is machine translated.
