Eaton EP-401400 Power supply unit 24 V 20 A 511 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 479.00 / piece)
€ 479.00
incl. VAT
14-day return policy included
Highlights & Details
Power supply, three-phase, 320 - 575 V AC / 24 V DC, 20 A
- Output 24 V / 20 A
- Power 511 W
- Screws
Technical specifications
- Type
Three phases
- Product type
Power supply unit
- Input voltage (max.)
575 V
- Max. output current
20 A
- Output current (max.) - rounded
20 A
- Min. input voltage
320 V
- Dim
(L x W x H) 124 x 65 x 127.3 mm
- Output voltage (max.)
24 V
- Connection
Screws
511 W
- Input frequency
50/60 Hz
IP20
- Operating temperature (max.)
70 °C
- Operating temperature (min.)
-25 °C
- Operating temperature
-25 °C - 70 °C
- Weight
1.2 kg
- Width
65 mm
- Height
127.3 mm
- Length
124 mm
- Type
PSG480F24SMB
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3553270 Eaton EP-401400 Power supply unit 24 V 20 A 511 W
User & Safety Instructions
User & Safety Instructions 3553270 Eaton EP-401400 Power supply unit 24 V 20 A 511 W
Description
Features
- Inaccessible internal input fuse (T3,15 AH/500 V) for equipment protection
