Ersa 0IC1105V0C Soldering station supply unit Digital 150 W 150 - 450 °C + soldering tip
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 676.47 / piece)
€ 676.47
plus VAT.
Only 7 Piece(s) available
Technical specifications
- Product type
Soldering station supply unit
- Max. power
150 W
- Power supply (LOV)
mains-powered
- Max. temperature
450 °C
- Display
Digital
- Preheat time
9 s
- Operating voltage
230 V
- Soldering iron features
+ soldering tip
- Min. temperature
150 °C
- Solder tip type
Long-life
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2902002 Ersa 0IC1105V0C Soldering station supply unit Digital 150 W 150 - 450 °C + soldering tip
User & Safety Instructions
User & Safety Instructions 2902002 Ersa 0IC1105V0C Soldering station supply unit Digital 150 W 150 - 450 °C + soldering tip
Description
Auxiliary acts · Deep notice · Suit case.
By developing the i-CON, ERSA has produced a soldering station that satisfies the requirements of increased operating temperatures and the ever smaller process window of lead-free soldering processes. The extremely small, light, ergonomic and powerful i-Tool soldering iron contributes greatly to improved quality, productivity and a huge reduction in operating costs. The i-CON 1V MK2 is naturally anti-static.
The Ersa filter devices can be connected to the version i-Con 1V C MK2 (with interface) in such a way that the standby signal is transferred to the filter. It then shuts down at the same time as the station. You can also connect and control a heating plate (e.g. 0IRHP100A-03) with the help of interface.
The integrated Tip'N'Turn bayonet lock makes it easy and quick to change tips and improves performance from 20-25% compared to screw connections.
Innovative technology – the highlights at a glance:
i-Tool soldering iron with 150 W micro high performance heating element
- User-friendly "One Touch" operation of the software
- Large multifunction display
- Three power levels
- Automatic stand-by sensor
- Interface for connection of a solder fume extraction system or a hot plate
- Power consumption in standby approx. 15W
- With Tip'N'Turn bayonet lock
This text is machine translated.
By developing the i-CON, ERSA has produced a soldering station that satisfies the requirements of increased operating temperatures and the ever smaller process window of lead-free soldering processes. The extremely small, light, ergonomic and powerful i-Tool soldering iron contributes greatly to improved quality, productivity and a huge reduction in operating costs. The i-CON 1V MK2 is naturally anti-static.
The Ersa filter devices can be connected to the version i-Con 1V C MK2 (with interface) in such a way that the standby signal is transferred to the filter. It then shuts down at the same time as the station. You can also connect and control a heating plate (e.g. 0IRHP100A-03) with the help of interface.
The integrated Tip'N'Turn bayonet lock makes it easy and quick to change tips and improves performance from 20-25% compared to screw connections.
Innovative technology – the highlights at a glance:
i-Tool soldering iron with 150 W micro high performance heating element
- User-friendly "One Touch" operation of the software
- Large multifunction display
- Three power levels
- Automatic stand-by sensor
- Interface for connection of a solder fume extraction system or a hot plate
- Power consumption in standby approx. 15W
- With Tip'N'Turn bayonet lock
This text is machine translated.
Scope of delivery
- 80W electronic station with interface (0IC1135V0C)
- I-Tool soldering iron 150W (0105CDJ)
- ERSADUR soldering tip 1.6 mm chisel-shaped (0142CDLF16)
- Rack (0A59)
