HARTING 09330102772 Socket inset Han® E 10 + PE Spring-loaded 1 pc(s)
EAN:
Part number:
Item no:
Product type
Socket inset
Series
Han® E
Connection
Spring-loaded
Total no. of pins
10 + PE
Factory colour
Grey
Datasheet (PDF)
8 Piece(s)
Sales and shipping:
Number
Total (€ 75.62 / piece)
€
Only 8 Piece(s) available
Highlights & Details
HARTING 09330102772 Socket inset Han® E 10 + PE Spring-loaded 1 pc(s)
Technical specifications
- Product type
Socket inset
- Factory colour
Grey
- Series
Han® E
- Features
copper-plated
tin-plated contacts
2 lugs per contact
- Connection
Spring-loaded
- Number of pins
10
- Total no. of pins
10 + PE
- Core cross section (min.)
0.14 mm²
- Core cross section (max.)
4 mm²
- Mating cycles
≥ 500
- Size
10 B
- Series
1 - 10
- Rated voltage
500 V
- Test current
16 A
- Content
1 pc(s)
- Max. temperature
+125 °C
- Min. temperature
-40 °C
- Leading contact (PE)
Yes
- Core connector
0.14 - 4 mm²
- Contamination level
3
- Temperature range
-40 - +125 °C
Documents & Downloads
Datasheet
Datasheet 742916 HARTING 09330102772 Socket inset Han® E 10 + PE Spring-loaded 1 pc(s)
Datasheet 742916 HARTING 09330102772 Socket inset Han® E 10 + PE Spring-loaded 1 pc(s)
User & Safety Instructions
User & Safety Instructions 742916 HARTING 09330102772 Socket inset Han® E 10 + PE Spring-loaded 1 pc(s)
Description
Heavy industrial connectors for the toughest requirements in automotive, machine and plant engineering.
