Picotronic Laser module Cross Infrared 2 mW CB 850-2-5 (16x45) 10 DEG F110
Product type
Laser module
Emission characteristics
Cross
Wavelength
850 nm
Power
2 mW
Laser category
1
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 189.99 / piece)
€ 189.99
incl. VAT
14-day return policy included
Highlights & Details
Laser module cross
- Infrared
- Laser category: 1
- Emission characteristics: Cross
Technical specifications
- Connection cable 100 mm
- Product type
Laser module
- Type
CB 850-2-5 (16x45) 10 DEG F110
- Emission characteristics
Cross
- Focus properties
110 mm fixed-focus
- Factory colour
Infrared
- Wavelength
850 nm
2 mW
- Laser category
1
- Angular aperture
10°
- Beam divergence
0.3 mrad
- Clearance
0.11 m
- Operating voltage
5 V DC
- Operating current
20 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+50 °C
- Min. temperature
-20 °C
Documents & Downloads
Datasheet
Datasheet 1695885 Picotronic Laser module Cross Infrared 2 mW CB 850-2-5 (16x45) 10 DEG F110
User & Safety Instructions
User & Safety Instructions 1695885 Picotronic Laser module Cross Infrared 2 mW CB 850-2-5 (16x45) 10 DEG F110
Information
Information 1695885 Picotronic Laser module Cross Infrared 2 mW CB 850-2-5 (16x45) 10 DEG F110
Conformity certificate
Conformity certificate 1695885 Picotronic Laser module Cross Infrared 2 mW CB 850-2-5 (16x45) 10 DEG F110
Description
Hints
Class 1: laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
