Picotronic Laser module DOE Red 5 mW DOE 635-5-3-S (22 x 112) - DOE - R260
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 293.28 / piece)
€ 293.28
plus VAT.
Only 4 Piece(s) available
Highlights & Details
Laser module DOE
- Red
- Laser category: 2M
- Emission characteristics: DOE
Technical specifications
- Type
DOE 635-5-3-S (22 x 112) - DOE - R260
- Emission characteristics
DOE
- Focus properties
4000 mm fixed-focus
- Factory colour
Red
- Wavelength
635 nm
5 mW
- Laser category
2M
- Beam divergence
0.6 mrad
- Clearance
0.4 m
- Operating voltage
3 V DC
- Operating current
60 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+50 °C
- Min. temperature
-20 °C
- Product type
Laser module
Documents & Downloads
Datasheet
Datasheet 1695873 Picotronic Laser module DOE Red 5 mW DOE 635-5-3-S (22 x 112) - DOE - R260
User & Safety Instructions
User & Safety Instructions 1695873 Picotronic Laser module DOE Red 5 mW DOE 635-5-3-S (22 x 112) - DOE - R260
Information
Information 1695873 Picotronic Laser module DOE Red 5 mW DOE 635-5-3-S (22 x 112) - DOE - R260
Conformity certificate
Conformity certificate 1695873 Picotronic Laser module DOE Red 5 mW DOE 635-5-3-S (22 x 112) - DOE - R260
Description
Scope of delivery
- incl. Batteries
- This text is machine translated.
Hints
Class 2M: laser radiation! Observe safety instructions! Never look into the beam (may damage your retina).
