Picotronic Laser module Dot Green 1 mW DG 520-1-5 (8 x 35) - QCW
Product type
Laser module
Emission characteristics
Dot
Wavelength
520 nm
Power
1 mW
Laser category
2
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 379.00 / piece)
€ 379.00
incl. VAT
Only 7 Piece(s) available
Highlights & Details
Laser module point
- Green
- Laser category: 2
- Emission characteristics: Dot
Technical specifications
- Connection cable 100 mm
- Product type
Laser module
- Type
DG 520-1-5 (8 x 35) - QCW
- Emission characteristics
Dot
- Focus properties
collimated
- Factory colour
Green
- Wavelength
520 nm
1 mW
- Laser category
2
- Beam divergence
0.8 mrad
- Clearance
30 m
- Operating voltage
5 V DC
- Operating current
40 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+60 °C
- Min. temperature
-10 °C
Documents & Downloads
Datasheet
Datasheet 1695852 Picotronic Laser module Dot Green 1 mW DG 520-1-5 (8 x 35) - QCW
User & Safety Instructions
User & Safety Instructions 1695852 Picotronic Laser module Dot Green 1 mW DG 520-1-5 (8 x 35) - QCW
Information
Information 1695852 Picotronic Laser module Dot Green 1 mW DG 520-1-5 (8 x 35) - QCW
Conformity certificate
Conformity certificate 1695852 Picotronic Laser module Dot Green 1 mW DG 520-1-5 (8 x 35) - QCW
Description
Hints
Class 2 laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
