Picotronic Laser module Expander Red 2 mW E 650-2 -3-30 (43 x 175)
EAN:
Part number:
Item no:
Product type
Laser module
Emission characteristics
Expander
Wavelength
650 nm
Power
2 mW
Laser category
1M
Datasheet (PDF)
Number
Total (€ 329.00 / piece)
€ 329.00
incl. VAT
Only 2 Piece(s) available
Highlights & Details
Laser module Expander
- Red
- Laser category: 1M
- Emission characteristics: Expander
Technical specifications
- Connection cable 100 mm
- Product type
Laser module
- Type
E 650-2 -3-30 (43 x 175)
- Emission characteristics
Expander
- Focus properties
5000 mm fixed-focus
- Factory colour
Red
- Wavelength
650 nm
2 mW
- Laser category
1M
- Beam divergence
0.6 mrad
- Clearance
30 m
- Operating voltage
3 V DC
- Operating current
42 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+50 °C
- Min. temperature
-20 °C
Documents & Downloads
Datasheet
Datasheet 1696027 Picotronic Laser module Expander Red 2 mW E 650-2 -3-30 (43 x 175)
User & Safety Instructions
User & Safety Instructions 1696027 Picotronic Laser module Expander Red 2 mW E 650-2 -3-30 (43 x 175)
Information
Information 1696027 Picotronic Laser module Expander Red 2 mW E 650-2 -3-30 (43 x 175)
Conformity certificate
Conformity certificate 1696027 Picotronic Laser module Expander Red 2 mW E 650-2 -3-30 (43 x 175)
Description
Hints
Class 1M: laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
