Picotronic Laser module Line Green 0.1 mW LC 520-0 1-5-F (16 x 65) - QCW-0

Picotronic Laser module Line Green 0.1 mW LC 520-0 1-5-F (16 x 65) - QCW-0

Picotronic Laser module Line Green 0.1 mW LC 520-0 1-5-F (16 x 65) - QCW-1

Picotronic Laser module Line Green 0.1 mW LC 520-0 1-5-F (16 x 65) - QCW-2

Picotronic Laser module Line Green 0.1 mW LC 520-0 1-5-F (16 x 65) - QCW-3

1/4

Picotronic

Datasheet (PDF)

English

Dispatches on Mon, 21 Sep

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 511.76 / piece)

€ 511.76

plus VAT.

Report legal concerns

Highlights & Details

Laser module line

Green
Laser category: 1
Emission characteristics: Line

Technical specifications

Connection cable 100 mm

Type: LC 520-0 1-5-F (16 x 65) - QCW

Emission characteristics: Line

Focus properties: Selectable focus

Factory colour: Green

Wavelength: 520 nm

: 0.1 mW

Laser category: 1

Angular aperture: 90°

Beam divergence: 0.4 mrad

Clearance: 1 m

Operating voltage: 5 V DC

Operating current: 43 mA

Material: Aluminium

RoHS-compliant: Yes

Max. temperature: +60 °C

Min. temperature: -10 °C

Product type: Laser module

Documents & Downloads

Datasheet

English

Datasheet 1695904 Picotronic Laser module Line Green 0.1 mW LC 520-0 1-5-F (16 x 65) - QCW

User & Safety Instructions

European union

User & Safety Instructions 1695904 Picotronic Laser module Line Green 0.1 mW LC 520-0 1-5-F (16 x 65) - QCW

Information

European union

Information 1695904 Picotronic Laser module Line Green 0.1 mW LC 520-0 1-5-F (16 x 65) - QCW

Conformity certificate

Conformity certificate 1695904 Picotronic Laser module Line Green 0.1 mW LC 520-0 1-5-F (16 x 65) - QCW

Description

Hints

Class 1: laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
