Picotronic Laser module Line Green 10 mW LH 520-10-24 (20 x 80)-PL-C 3000-WP
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 794.12 / piece)
€ 794.12
plus VAT.
Only 3 Piece(s) available
Highlights & Details
Laser module line
- Green
- Laser category: 1M
- Emission characteristics: Line
Technical specifications
- Connection cable 3000 mm
- Type
LH 520-10-24 (20 x 80)-PL-C 3000-WP
- Emission characteristics
Line
- Focus properties
3000 mm fixed-focus
- Factory colour
Green
- Wavelength
520 nm
10 mW
- Laser category
1M
- Angular aperture
90°
- Beam divergence
1.0 mrad
- Clearance
5 m
- Operating voltage
24 V DC
- Operating current
55 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+60 °C
- Min. temperature
-10 °C
- Product type
Laser module
Documents & Downloads
Datasheet
Datasheet 1695888 Picotronic Laser module Line Green 10 mW LH 520-10-24 (20 x 80)-PL-C 3000-WP
User & Safety Instructions
User & Safety Instructions 1695888 Picotronic Laser module Line Green 10 mW LH 520-10-24 (20 x 80)-PL-C 3000-WP
Information
Information 1695888 Picotronic Laser module Line Green 10 mW LH 520-10-24 (20 x 80)-PL-C 3000-WP
Conformity certificate
Conformity certificate 1695888 Picotronic Laser module Line Green 10 mW LH 520-10-24 (20 x 80)-PL-C 3000-WP
Description
Hints
Class 1M: laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
