Picotronic Laser module Line Green 5 mW LD 532-5-24 (16x80) 30-C2000-F500
Product type
Laser module
Emission characteristics
Line
Wavelength
532 nm
Power
5 mW
Laser category
1
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 399.00 / piece)
€ 399.00
incl. VAT
Only 7 Piece(s) available
Highlights & Details
Laser module line
- Green
- Laser category: 1
- Emission characteristics: Line
Technical specifications
- Connection cable 2000 mm
- Product type
Laser module
- Type
LD 532-5-24 (16x80) 30-C2000-F500
- Emission characteristics
Line
- Focus properties
Fixed-focus
- Factory colour
Green
- Wavelength
532 nm
5 mW
- Laser category
1
- Angular aperture
30°
- Beam divergence
0.5 mrad
- Clearance
0.5 m
- Operating voltage
24 V DC
- Operating current
30 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+30 °C
- Min. temperature
-15 °C
Documents & Downloads
Datasheet
Datasheet 1695951 Picotronic Laser module Line Green 5 mW LD 532-5-24 (16x80) 30-C2000-F500
User & Safety Instructions
User & Safety Instructions 1695951 Picotronic Laser module Line Green 5 mW LD 532-5-24 (16x80) 30-C2000-F500
Information
Information 1695951 Picotronic Laser module Line Green 5 mW LD 532-5-24 (16x80) 30-C2000-F500
Conformity certificate
Conformity certificate 1695951 Picotronic Laser module Line Green 5 mW LD 532-5-24 (16x80) 30-C2000-F500
Description
Hints
Class 1: laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
