SVS Nachrichtentechnik SHT-12 FS 4-channel Fixed transmitter Max. range (open field): 1000 m

The radio transmitter SHT-12 FS enables the remote control of up to 4 functions of a radio module or receiver of the radio series SH-12.

With the new hard transmittor SHT-12 FS are switching signals of relay contacts, buttons or switches without any installation effort for control lines. It has 4 inputs for floating contacts. For each of the 4 inputs, the operating mode of scan or switching signal transmission can be set.

With the momentary signal transmission corresponds to the end of the contact duration, the transmission path remains while the signal is present, occupies. With the switch signal transmission is only a state changes to the input a radio signal transfer and thus, the radio link is not permanently blocked.

A blue LED indicates the transmission is in operation. It is not only sent radio signals, but also gives information about the quality of the radio communication and the transmitter power supply. The red LED displays, depending on the wiring on the radio receiver either the status of the receiver supply voltage or the input on the receiver confirmation. Via an integrated beeper is a confirmation of the receiver also signalled acoustically. Is the confirmation is disabled, any change of the input status reported instead.

The radio transmitter of the radio series SH-12 due to their special transmission properties Extremely low disturbance. With the lack of interference-resistant radio transmission with extremely short response times can range over 1000 m can be achieved.

For strong narrow-band interference or the use of multiple parallel radio systems, the operating frequency for the individual requirements can be set. The radio series SH-12 can be operated both unidirectional as well as bi-directional. At the bi-directional communication, the sender fits its transmission behavior automatically to the quality of the radio range. The transmitters are supplied from the factory with a continuous series number is programd. This provides greater safety and makes each transmitter to a clearly separable unique.
