Name: Tamiya 1:10 RC model car Electric Road version 4WD Kit
Brand: Tamiya
SKU: 3089033
Availability: InStock

Model car with a transparent casing, revealing the internal wiring and shock absorbers. The car has four thick tyred wheels with tread.

'Diagram of an RC car chassis with marked components: motor, drive shaft, shock absorbers, steering servo, receiver, ESC and battery.'

Remote-controlled car chassis with visibly mounted electronics, battery and suspension on four large wheels, side view.

RC model chassis with wheels, exposed electronics and battery.

'XM-01 PRO Chassis Kit' by Tamiya, with four-wheel drive. Detailed graphic of the chassis from above, showing components and construction.

1/5

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

1 Piece(s) (Only while stocks last)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 285.00 / piece)

€ 285.00

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Technical specifications

Product type: RC model car

Model craft type: Road version

Scale: 1:10

Drive: 4WD

Model version: Kit

Age category: 14 years and over

Engine type: Electric

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3089033 Tamiya 1:10 RC model car Electric Road version 4WD Kit

Description

The XM-01 Pro chassis is a tuning chassis for all M-Chassis. The chassis possess numerous tuning parts from the house and is based on its big brother XV-02.
The model can be built in 3 different wheel stands: 210mm (short), 225mm (medium), 239mm (long) and can thus be adapted to different M-Chassis.
The chassis has a tub frame and a polycarbonate chassis cover. Additional mud guards prevent serious dirt from entering rally cars.
The all wheel drive can be tuned using different differential gears. 1:1 Transmission with the 39-series front and rear gears or a 40-series gear for more drive at the rear axle or front axle.

This text is machine translated.

Features

Kit model in the scale of 1/10
XM-01 chassis with 4WD drive
Centrally installed motor, along the direction of travel
By changing the rear housing in 3 different wheel stands, it can be built: 210mm (short), 225mm (medium), 239mm (long)
Pan frame chassis and polycarbonate tub-cover and mud guards prevent the penetration of coarse dirt during rally drives
C hubs and rear axle beams allow construction in 2 different vehicle heights/ground clearance (8mm and 13mm).
Follow-up can be set to 5 degrees
Oil-filled differentials
Two 39 teeth diff and a 40 teeth diff for the adjustment of the drive balance (front/rear drive balance)
Front bumper
Aluminium oil-pressure shock absorbers front and rear
M-chassis 11-spokes racing rims (51394) and 60D rally Block tires (51427)
Universal cardan shaft front and rear
Slipper optional
Compatible with numerous tuning parts of the Tamiya XV-02 chassis

Scope of delivery

4WD kit model
XM-01 Chassis
3-different wheel bases can be built
Chassis-Cover
Numerous tuning parts
Inclusive of instructions

System requirements

Required accessories: Remote control with receiver, steering servo, 7.2V NiMH battery pack, motor, M-chassis body, Charger, color for polycarbonate body (Tamiya PS-)
