Buy TracoPower TMM 24115C AC/DC PSU (print) 15 V DC 1.6 A 24 W

Black Traco Power module with red details, model TMW 12-215C. Features connections at both ends, labelled with 'AC', 'NC'.

Datasheet (PDF)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Minimum order quantity: 5

Total (€ 80.66 / piece)

€

Report legal concerns

Highlights & Details

AC/DC-SWITCHED POWER SUPPLY, 24 W, 15 V/1.6 A

Output 15 V DC / 1.6 A
Power 24 W

Technical specifications

Max. output current: 1.6 A

Output current (max.) - rounded: 1.6 A

Dim: (L x W x H) 96 x 54 x 23.3 mm

Height: 23.3 mm

Length: 96 mm

Width: 54 mm

Type: TMM 24115C

Input voltage (max.): 264 V AC

Min. input voltage: 85 V AC

Operating temperature (max.): 80 °C

Operating temperature (min.): -40 °C

Max. operating temperature (derating): 90 °C

Min. operating temperature (derating): 65 °C

Output voltage (max.): 15 V DC

No. of outputs: 1 x

: 24 W

Weight: 147 g

Product type: AC/DC PSU (print)

Documents & Downloads

Datasheet

Datasheet 3370096 TracoPower TMM 24115C AC/DC PSU (print) 15 V DC 1.6 A 24 W

User & Safety Instructions

User & Safety Instructions 3370096 TracoPower TMM 24115C AC/DC PSU (print) 15 V DC 1.6 A 24 W

Warranty Terms

Warranty Terms 3370096 TracoPower TMM 24115C AC/DC PSU (print) 15 V DC 1.6 A 24 W

Description

The switching power supplies of the TMM 24 series offer ultra-compact, completely sealed modules with reinforced/double I/O insulation according to the latest safety standards 60601-3, 3rd edition for 2 x MOPP (Means Of Patient Protection). Due to their high degree of efficiency and the use of high-quality components, these modules can be used in a working temperature range from –40°C to +65°C, with a power reduction of 50% even up to +80°C. Due to their good EMC properties, they can be used not only in medical applications but also in demanding industrial and transport applications.

This text is machine translated.
