TracoPower TMP 15252 AC/DC PSU (print) 5 V DC 1.5 A 15 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Minimum order quantity: 5
Total (€ 53.99 / piece)
€ 53.99
incl. VAT
14-day return policy included
Highlights & Details
TracoPower TMP 15252 AC/DC PSU (print) 5 V DC 1.5 A 15 W
- Ultra compact and flat
- AC- and DC-input
Technical specifications
- Product type
AC/DC PSU (print)
- Input voltage (max.)
264 V AC
- Max. output current
1.5 A
- Output current (max.) - rounded
1.5 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 19.5 x 54.0 x 74.0 mm
- Output voltage (max.)
5 V DC
- Connection
Solder pins
15 W
- No. of outputs
2 x
- Type
closed
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
50 °C
- Min. operating temperature (derating)
-25 °C
- Weight
114 g
- Type
Synchronised
- Width
54.0 mm
- Height
74.0 mm
- Length
19.5 mm
- Type
TMP 15252
- Connection
Soldering pins
- Input voltage
90 - 264 V/AC/120 - 370 V DC
- Max. temperature
60 °C
- Min. temperature
-25 °C
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3371524 TracoPower TMP 15252 AC/DC PSU (print) 5 V DC 1.5 A 15 W
User & Safety Instructions
User & Safety Instructions 3371524 TracoPower TMP 15252 AC/DC PSU (print) 5 V DC 1.5 A 15 W
Warranty Terms
Warranty Terms 3371524 TracoPower TMP 15252 AC/DC PSU (print) 5 V DC 1.5 A 15 W
Description
Shed power supply module for PCB mounting with solder pins for chassis mounting with screw terminals. The module is designed for AC and DC capable operation TMPM version with ultra-compact design.
Features
- Short-circuit and overload protection
- Power limitation at: > 120-180% Inorm with foldback
- Safety standards / approvals: cUL / UL 60950-1, IEC / EN 60950-1, CB-Report
- Operating temperature: -25 to +60 ºC, derating>50 °C
- Housing as of UL 94V-0
