TracoPower TMPW 25-115-J SMPSU 15 V DC 1.66 A 25 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 27.72
30
4% = € 1.21
€ 26.51
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 27.72 / piece)
€ 277.20
plus VAT.
14-day return policy included
Highlights & Details
AC/DC switched-mode power supply, TMPW 25-J series
- Output 15 V DC / 1.66 A
- Power 25 W
- Jack connector
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
305 V AC
- Max. output current
1.66 A
- Output current (max.) - rounded
1.66 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 88.4 x 38.1 x 24.1 mm
- Output voltage (max.)
15 V DC
- Connection
Jack connector
25 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Operating temperature (min.)
-40 °C
- Weight
100 g
- Width
38.1 mm
- Height
24.1 mm
- Length
88.4 mm
- Type
TMPW 25-115-J
Documents & Downloads
Datasheet
Datasheet 3372566 TracoPower TMPW 25-115-J SMPSU 15 V DC 1.66 A 25 W
Datasheet 3372566 TracoPower TMPW 25-115-J SMPSU 15 V DC 1.66 A 25 W
User & Safety Instructions
User & Safety Instructions 3372566 TracoPower TMPW 25-115-J SMPSU 15 V DC 1.66 A 25 W
Warranty Terms
Warranty Terms 3372566 TracoPower TMPW 25-115-J SMPSU 15 V DC 1.66 A 25 W
