Triax GDA 313 Antenna socket SAT, TV, FM Flush mount Non-terminated
EAN:
Part number:
Item no:
Number
Total (€ 21.99 / piece)
€ 21.99
incl. VAT
Only 8 Piece(s) available
Highlights & Details
Triax GDA313F pass-through socket
- Suitable for SAT-ZF and BK-house distribution systems
- Remote feed capable via SAT-outlet
Technical specifications
- Type
Non-terminated
- Product type
Antenna socket
- Suitable for
SAT
TV
FM
- Mounting type
Flush mount
- Features
Reverse channel
- FM (min.)
5 MHz
- FM (max.)
118 MHz
- TV signal frequency (min.)
5 MHz
- TV signal frequency (max.)
862 MHz
- SAT frequency (min.)
950 MHz
- SAT frequency (max.)
2400 MHz
- No. of FMs
1 x
- No. of TVs
1 x
- No. of SATs
1 x
- SAT signal attenuation
10 dB
- Factory colour
Silver
- Dim
(L x W x H) 70.6 x 21.9 x 70.6 mm
- Width
21.9 mm
- Height
70.6 mm
- Length
70.6 mm
- Weight
0.111
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1646065 Triax GDA 313 Antenna socket SAT, TV, FM Flush mount Non-terminated
Description
GDA313F gateway socket for uni-cable systems.
This text is machine translated.
This text is machine translated.
Features
- 3-Hole Allround Antenna socket with integrated frequency bands, so flexible and future-proof
- Complete BK and sat-bereiche and low distribution losses through combined filter distributor-structure, return-channel compatible
- Caution: at dc voltage on the main line (13/18V) terminating resistor with direct current separation R 77 DCB use
Scope of delivery
- Antenna socket
