Ubiquiti Networks USW-PRO-MAX-24-POE UniFi USW Pro Max Network switch 24 + 2 ports
EAN:
Part number:
Item no:
Number
Total (€ 881.51 / piece)
€ 881.51
plus VAT.
Only 3 Piece(s) available
Ubiquiti Unifi Pro Max 24 PoE - Switch - L3 - managed - 8 x 1/2.5G (PoE++)
Highlights & Details
- 24 port configuration with a mix of Gigabit Ethernet and 2.5 Gigabit Ethernet for flexible connectivity
- 400 W PoE-budget for supporting different PoE-devices
- 56 Gbps of non-blocking throughput for efficient data processing
- Advanced Layer 3 switching features for improved network management
- Rack-mountable design with supplied mounting kit for easy integration
Technical specifications
- Housing type: Mountable onto rack 1U
- Power over Ethernet PoE+, PoE+
- PoE budget 400 W
- Performance: Non-blocking selectable throughput: 56 Gbit/s; switching capacity: 112 Gbit/s.
- Jumbo frame support: Yes
- Routing protocol: STP, RSTP, static IP routing
- Remote management protocol: DHCP
- Features: Etherlighting ports, IGMP snooping, connection isolation, Storm Control, Voice VLAN, port mirroring, LACP support, frequency limit, MAC address filter, flow control, Loop detection, DHCP snooping, LLDP-MED, DHCP relay, Inter-VLAN routing
- Certified IEEE 802.1x
- Display: 1.3" touch-screen display
- Status indicator: Port location, link/speed, VLAN, system, RPS (redundant power supply)
- Product type
Network switch
- LAN transfer rate
10 MBit/s
100 MBit/s
1000 MBit/s
2500 MBit/s
10000 MBit/s
- Working principle
Managed switch
- Ethernet ports
24
- SFP+ ports
2 x
- Port type
8 x 1000Base-T RJ-45 PoE+ - 30 W + 8 x 1000Base-T RJ-45 PoE++ - 60 W + 8 x 1/2.5GBase-T RJ-45 PoE+ - 60 W + 2 x 10Gbit LAN SFP+
- Power supply (LOV)
mains-powered
- Weight
5.1 kg
- Width
442 mm
- Height
44 mm
- Depth
325 mm
- Type
UniFi USW Pro Max
- Rack size
483 mm (19")
- Interfaces
RJ45
RJ45 2.5 Gbit (LAN) port
SFP+
- Factory colour
Silver
- Current consumption
Alternating current 100-240 V (50/60 Hz)
- Max. ambient temperature
-5 °C
- Min. ambient temperature
+40 °C
- Port
24 + 2 ports
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3373152 Ubiquiti Networks USW-PRO-MAX-24-POE UniFi USW Pro Max Network switch 24 + 2 ports
Description
The Ubiquiti Unifi Pro Max 24 PoE switch is a powerful solution that meets the requirements of modern companies. With its 24 ports, of which 8 1/2.5G (PoE+) and 16 10/100/1000 (8 PoE+, 8 PoE+) support, this switch offers flexibility when connecting a variety of devices. The 2 10-Gigabit SFP+ ports expand connectivity options and make it Ideal for high-speed network requirements.
This switch offers excellent connectivity and robust performance with a non-blocking switching throughput of 56 Gbit/s and a switching capacity of 112 Gbit/s, ensuring WAS a smooth and efficient management of data traffic. The generous PoE budget of 400 W makes possible the power supply of numerous devices directly via the network cable, WAS reduces the mess and simplifies the installation.
Designed for ease of use and reliability, the Ubiquiti Unifi Pro Max 24 PoE switch features a 1.3-inch touchscreen display that allows easy monitoring and configuration. Its advanced layer 3 switching functions, including DHCP snooping, IGMP Snooping and more, offer improved security and network management. By complying with FCC and IC standards and rugged, rackmountable design, this switch is a reliable backbone for any corporate network.
Advanced connectivity
The Ubiquiti Unifi Pro Max 24 PoE switch offers a variety of ports, including 8 1/2.5G (PoE+) and 16 10/100/1000 (8 PoE+, 8 PoE+) ports and 2 10 Gigabit SFP+ ports, which offer versatile connectivity options for a wide range of devices.
Robust performance
With a non-blocking switching throughput of 56 Gbit/s and a switching capacity of 112 Gbit/s, this switch is designed to handle high data volumes and offers reliable and efficient network performance.
Improved power supply
With a generous PoE budget of 400 W and support for PoE+ and PoE++ at several ports, the switch can provide power to a variety of devices, from modern surveillance cameras to VoIP phones, without the need for additional power sources.
Intuitive management
Fitted with a 1.3-inch touch screen display for easy monitoring and advanced layer 3 switching functions, this switch offers DHCP snooping, IGMP Snooping and more for improved network security and management.
Durable and compliant
The switch is designed for longevity and meets the FCC and IC standards. It comes with a rack mounting kit that is easy to install into any standard rack, making it a reliable choice for any business infrastructure.
This text is machine translated.
This switch offers excellent connectivity and robust performance with a non-blocking switching throughput of 56 Gbit/s and a switching capacity of 112 Gbit/s, ensuring WAS a smooth and efficient management of data traffic. The generous PoE budget of 400 W makes possible the power supply of numerous devices directly via the network cable, WAS reduces the mess and simplifies the installation.
Designed for ease of use and reliability, the Ubiquiti Unifi Pro Max 24 PoE switch features a 1.3-inch touchscreen display that allows easy monitoring and configuration. Its advanced layer 3 switching functions, including DHCP snooping, IGMP Snooping and more, offer improved security and network management. By complying with FCC and IC standards and rugged, rackmountable design, this switch is a reliable backbone for any corporate network.
Advanced connectivity
The Ubiquiti Unifi Pro Max 24 PoE switch offers a variety of ports, including 8 1/2.5G (PoE+) and 16 10/100/1000 (8 PoE+, 8 PoE+) ports and 2 10 Gigabit SFP+ ports, which offer versatile connectivity options for a wide range of devices.
Robust performance
With a non-blocking switching throughput of 56 Gbit/s and a switching capacity of 112 Gbit/s, this switch is designed to handle high data volumes and offers reliable and efficient network performance.
Improved power supply
With a generous PoE budget of 400 W and support for PoE+ and PoE++ at several ports, the switch can provide power to a variety of devices, from modern surveillance cameras to VoIP phones, without the need for additional power sources.
Intuitive management
Fitted with a 1.3-inch touch screen display for easy monitoring and advanced layer 3 switching functions, this switch offers DHCP snooping, IGMP Snooping and more for improved network security and management.
Durable and compliant
The switch is designed for longevity and meets the FCC and IC standards. It comes with a rack mounting kit that is easy to install into any standard rack, making it a reliable choice for any business infrastructure.
This text is machine translated.
Scope of delivery
- Ubiquiti Unifi Pro Max 24 PoE
- Rack mounting kit
