WAGO 750-653/000-002 PLC serial interface 750-653/000-002 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 445.00 / piece)
€ 445.00
incl. VAT
14-day return policy included
Technical specifications
- RS 485 9600/E/8/1
- Product type
PLC serial interface
- Interfaces
RS 485
Terminals
- Type
750-653/000-002
- No. of inputs (max.)
1
- No. of outputs (max.)
1
- Height
65 mm
- Length
100 mm
- Width
51 mm
- Max. ambient temperature
+55 °C
- Min. ambient temperature
0 °C
- Dim
(L x W x H) 100 x 51 x 65 mm
- Manufacturer part #
750-653/000-002
- Weight
48.5 g
- Connection
Clamp
- Mounting type
DIN rail
- Operating voltage
Via the system voltage DC/DC
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 192056 WAGO 750-653/000-002 PLC serial interface 750-653/000-002 1 pc(s)
User & Safety Instructions
User & Safety Instructions 192056 WAGO 750-653/000-002 PLC serial interface 750-653/000-002 1 pc(s)
Description
RS-485/9600/E/8/1, light gray.
This text is machine translated.
This text is machine translated.
