Chamberlain RPD10ER-10 Wireless tubular motor set 40 mm 20 kg 165 W 10 Nm
EAN:
Part number:
Item no:
Number
Total (€ 105.03 / piece)
€ 105.03
plus VAT.
Only 5 Piece(s) available
Highlights & Details
Wireless tubular motor set Chamberlain RPD10ER-10 10 Nm
- Max. Shutter surface (PVC) 5 m²Max. Shutter surface (ALU) 4 m²Max. Shutter surface (wood) 2 m²
Technical specifications
- Max. Operating time: 4 min.
- Product type
Wireless tubular motor set
- Suitable for shutter axle Ø
40 mm
- Motor power
165 W
- Dim
(Ø x H) 35 mm x 35 mm
- Weight
1.6 kg
- Rotational speed
17 U/min
- Length
490 mm
- Tensile force (max.)
20 kg
- Obstacle detection
Yes
- Operating voltage
230 V
- Width
35 mm
- Height
35 mm
- (Ø)
35 mm
- Hub
Not required
- Data exchange
Bidirectional (bi)
- Torque
10 Nm
- Features
incl. 1 remote control
- Lead length
1.8 m
- Factory colour
Blue
- Power consumption
165 W
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2587772 Chamberlain RPD10ER-10 Wireless tubular motor set 40 mm 20 kg 165 W 10 Nm
Description
Radio-controlled roller shutter drive with a pulling force of 10 Nm suitable for shutters weighing up to 20 kg.
This text is machine translated.
This text is machine translated.
Features
- For octagonal shaft 40 mm ØSets the end points with the supplied 1-channel hand-held transmitterAutomatic obstacle detection.
Scope of delivery
- Incl. 1 hand-held transmitter 1-channel
- 1.8 m connecting cable.
