Highlights & Details
LAN, Wi-Fi IP-Rotatable/tilting camera;2560 x 1440 p;INSTARIN-9420;14092Outdoors
- 2K+ video resolution
- With integrated Zoom
- AI-based object detection
- Built-in PIR sensor
- Time lapse recordings
- IP66 weather-protected
Technical specifications
- Pan & Tilt: 350° pan 100° tilt
- Viewing angle: Approx. 30-120°
- Optical Zoom 5 x
- Video compression (Codec): H265 / H264 / MJPEG
- Min Resolution 1280x720
- Max. Resolution: 2560x1440
- Frame rate 30fps (2K+)
- Image (rotate / mirror): 180°, Yes
- LAN-connection (RJ45) 10/100 MBit
- Integrated PoE: Yes
- Integrated WLAN: Up to 433 Mbit
- Wi-Fi frequency band 2.4 GHz / 5 GHz
- Built-in SD card: 32GB MicroSD (max. 256GB)
- Built-in Infrared LEDs:6 high-performance infrared LEDs / 6 white light-LEDs
- Product type
CCTV camera
- CCTV features
Saves footage on SD card
2-way communication
Speaker
Microphone
IR LEDs
White spotlight
Optical zoom
Pan-tilt function
- Camera type
Rotatable/tilting camera
- Power supply
PSU
PoE (Power over Ethernet)
- Resolution (max.)
2560 x 1440 p
- Sensor size
9.07 mm (1/2.8")
Apple HomeKit
- Focal length
2,7 - 13,5 mm
- App compatibility
Yes
- Transfer type
LAN
Wi-Fi
- IR range (max.)
30 m
- Used at
Outdoors
- Type
microSD card (up to 256 GB)
- Width
150 mm
- Height
230 mm
- Depth
150 mm
- Dim
(W x H x D) 150 x 230 x 150 mm
- Weight
1900 g
- Factory colour
White
IP66
- Signal standard
IP
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3203173 INSTAR IN-9420 14092 LAN, Wi-Fi IP CCTV camera 2560 x 1440 p
Description
The IN-9420 2K+ integrates seamlessly with leading smart home systems such as MQTT, HomeKit, alarm server and RTSP, marking the peak of sophisticated security technology.
With an integrated LAN connection, Wi-Fi module compatible with the 2.4 GHz and 5 GHz bands, and an integrated PoE module, the camera can easily be connected to a Power over Ethernet switch. Users have the flexibility to decide how they want to integrate the camera into their existing network. Increase your security standards with the comprehensive and intelligent coverage of the INSTAR IN-9420 2K+.
