Modelcraft RB350050-0A101R Gearmotor 12 V 1:50
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 25.99 / piece)
€ 25.99
incl. VAT
14-day return policy included
Technical specifications
- Operating voltage
12 V
- Product type
Gearmotor
- Nominal voltage
12 V
- Dim
(Ø x L) 37 mm x 74.5 mm
- Gear reduction
1:50
- Load speed
104 U/min
- Max. transmission load
9 kg/cm · permanent 3 kg/cm
- Max. load current
2.1 A
- Idle speed (nominal)
120 U/min
- Shaft length
12 mm
- Length
74.5 mm
- (Ø)
37 mm
- Peak torque
90 Ncm
- Gear reduction (details)
50:1
- Shaft Ø
6 mm
Documents & Downloads
Datasheet
Datasheet 227552 Modelcraft RB350050-0A101R Gearmotor 12 V 1:50
User & Safety Instructions
User & Safety Instructions 227552 Modelcraft RB350050-0A101R Gearmotor 12 V 1:50
Description
Excellently machined, high resistance, quiet, small yet still offering high efficiency. The input and output shafts are offset slightly.
Features
- Motor idling speed 6000 rpm
- Motor load speed 4650 rpm
- Motor torque 35 g/cm
- Motor idling current consumption approx. 80 mA (without gearbox)
- Motor current consumption under load approx. 300 mA
- Motor diameter 35 mm
- Gearbox diameter 37 mm
- Efficiency 66 %.
