Phoenix Contact 1701934 Spring-loaded terminal 6.00 mm² Number of pins 4 Blue, Gun grey, Black, Red 50 pc(s)
EAN:
Part number:
Item no:
Product type
Spring-loaded terminal
CS
7.50 mm
Pins per row
4
Number of pins
4
Connection
Spring-loaded terminal
Print
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 4.12 / piece)
€ 218.49
-6 %
€ 205.87
plus VAT.
14-day return policy included
Technical specifications
- Type
SPT 5/ 4-V-7,5-ZB BU/GY/BK/RD
- Product type
Spring-loaded terminal
- Features
+ push-in spring bracket
- CS
7.50 mm
- No. of rows
1
- Pins per row
4
- Number of pins
4
- Series
SPT
- Min. stripping length
15 mm
- Stripping length (max.)
15 mm
- Connection
Spring-loaded terminal
Print
- Nominal current
41 A
- Nominal current - rounded value
41 A
- Cross section (flexible) (max.)
6.00 mm²
- Cross section (inflexible) (max.)
6.00 mm²
- AWG (min.)
24
- Connector orientation
Perpendicular (to the PCB)
- AWG max.
8
- Contact material
Tin plated
- Factory colour
Blue
Gun grey
Black
Red
- Wire protection
Yes
- Manufacturer part #
1701934
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
1000 V
- Width
31.80 mm
- Height
28.75 mm
- Length
18.50 mm
Documents & Downloads
Datasheet
Datasheet 193079 Phoenix Contact 1701934 Spring-loaded terminal 6.00 mm² Number of pins 4 Blue, Gun grey, Black, Red 50 pc(s)
User & Safety Instructions
User & Safety Instructions 193079 Phoenix Contact 1701934 Spring-loaded terminal 6.00 mm² Number of pins 4 Blue, Gun grey, Black, Red 50 pc(s)
Description
PCB terminal block, nominal current: 41 A, nominal voltage: 800 V, pitch: 7.5 mm, number of positions: 4, connection method: spring-cage connection, assembly: soldering, conductor/PCB connection direction: 90°, color: blue, gray, black, red
Hints
Special order, no right of withdrawal.
