Rigol DG4102 Mains-powered 0.000001 Hz - 100 MHz 2-channel Sinus, Rectangle, Pulse, Noise, Arbitrary, Triangle
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 847.90 / piece)
€ 847.90
plus VAT.
14-day return policy included
Highlights & Details
Arbitrary function generator DG4102
- 2 channels
- Bandwidth: 100 MHz
- 14-bit vertical resolution
- Integrated frequency counters
Technical specifications
- Offset: ± 5 Vpk
- Curve Memory: 16 kpts
- Impedance 50 Ω
- Display: Color-TFT 17.7 cm, 800 x 480 pixels
- Length: 117 mm
- Signal output type
Sine, square, triangle, pulse, noise, harmonious, arbitrary
- Product type
Mains-powered
- Frequency range
0.000001 Hz - 100 MHz
- Signal output types
Sinus
Rectangle
Pulse
Noise
Arbitrary
Triangle
- Frequency range (sine)
1 µHz - 100 MHz
- Distortion factor (sine)
<0.1 %
- Frequency range square wave
1 µHz - 40 MHz
- Square wave slew rate
<10 ns
- Display
LCD
- Frequency range triangle
1 µHz - 3 MHz
- ARB frequency range
1 µHz - 25 MHz
Manufacturer's standards (no certificate)
- Wobble function
1 ms - 300 s
- Internal modulation
AM, FM, PM, ASK, FSK, PSK, BPSK, QPSK, 3-FSK, 4-FSK, OSK, PWM
- Frequency reading (external)
1 µHz - 200 MHz
- Dim
(W x H) 313 mm x 161 mm
- Weight
3.2 kg
- No. of channels
2-channel
- Max. frequency
100 MHz
- Min. frequency
0.000001 Hz
- Features
Modulation
- Width
313 mm
- Height
161 mm
- Interfaces
USB
USB host
LAN
- Voltage supply
Mains
- Type
DG4102
Documents & Downloads
Datasheet
Datasheet 409752 Rigol DG4102 Mains-powered 0.000001 Hz - 100 MHz 2-channel Sinus, Rectangle, Pulse, Noise, Arbitrary, Triangle
User & Safety Instructions
User & Safety Instructions 409752 Rigol DG4102 Mains-powered 0.000001 Hz - 100 MHz 2-channel Sinus, Rectangle, Pulse, Noise, Arbitrary, Triangle
Conformity certificate
Conformity certificate 409752 Rigol DG4102 Mains-powered 0.000001 Hz - 100 MHz 2-channel Sinus, Rectangle, Pulse, Noise, Arbitrary, Triangle
Warranty Terms
Warranty Terms 409752 Rigol DG4102 Mains-powered 0.000001 Hz - 100 MHz 2-channel Sinus, Rectangle, Pulse, Noise, Arbitrary, Triangle
Description
The arbitrary function generator DG4102 has 2 output channels with switchable frequency and phase coupling as well as an internal memory. In addition to the typical signal functions sine, square, triangle, pulse, noise and harmonious are over 140 arbitrary signals such as ECG, Gauss curves, Lorentz, Dual Tone, Expotential Rise and fall, etc. pre-programd.
This text is machine translated.
This text is machine translated.
Features
- Large 17.8 cm color monitor (800 x 480 pixels)
- Modulation types: AM, FM, PM, ASK, FSK, PSK, BPSK, QPSK, 3-FSK, 4-FSK, OSK, PWM
- Wobble function
- Burst
- External trigger input
- Remote control via USB and LAN (LXI-C)
- Harmonic function up to 16. Order
- Powerful generator software.
Scope of delivery
- Power cord
- USB cable
- 1 m BNC cable
- CD with software and manual
- Quick guide.
