Name: Tektronix MSO24 2-BW-500 + MSO24 2-P6139B Digital 500 MHz 1.25 GS/s 8 Bit Mixed signal (MSO) 1 pc(s)
Brand: Tektronix
SKU: 2585649
Availability: BackOrder

Highlights & Details

Oscilloscope,4 CH, 500MHz + Probe P6139B

500 MHz
No. of analogue inputs 4

Technical specifications

Product type: Digital

Bandwidth: 500 MHz

Channel sample rate: 1.25 GS/s

Resolution: 8 Bit

Screen size: 10.1 inch

Oscilloscope features: Mixed signal (MSO)

No. of analogue inputs: 4

: Manufacturer's standards (no certificate)

Reading category: CAT II 300 V

Input impedance: 10 MΩ

Power supply (details): 230 V AC

Dim: (L x W x H) 344 x 210 x 40.4 mm

Display: 1280 x 800 p

Width: 210 mm

Height: 40.4 mm

Length: 344 mm

Type: MSO24 2-BW-500 + MSO24 2-P6139B

Documents & Downloads

Datasheet

Datasheet 2585649 Tektronix MSO24 2-BW-500 + MSO24 2-P6139B Digital 500 MHz 1.25 GS/s 8 Bit Mixed signal (MSO) 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2585649 Tektronix MSO24 2-BW-500 + MSO24 2-P6139B Digital 500 MHz 1.25 GS/s 8 Bit Mixed signal (MSO) 1 pc(s)

Description

Compact, versatile oscilloscope for daily troubleshooting. A large, high-resolution, capacitive touch display provides a class-leading relationship between the screen and the housing. Passive voltage probes are included as standard with most oscilloscopes and are a cost-effective multi-purpose probe solution. In general, the performance of these probes is lower than that of an active voltage probe. However, they have the robustness and the wide dynamic range, which make them ideal for visualizing signals in a variety of applications. Tektronix has revolutionized the passive probe category with its new class of passive probes.

This text is machine translated.

Features

Passive voltage probeBest bandwidth of up to 1 GHzMinimum load impact of the probe head through the industry's best input capacity of surprisingly low 3.9 pFMinimal power losses when using long ground conductors thanks to the industry's best input capacityAutomated probe compensation, which means that no compensation screwdriver is needed any more300 V CAT II DYNAMIC RANGEBandwidth: 500 MHzInput impedance at probe tip: 10 MΩ, 8 pFCable length: 1,3 m
