Telegärtner 100007525 Telegärtner 100007525 N/A 100007525 Socket, straight Pins: 8P8C 1 pc(s) 100007525 Socket, straight
Product type
RJ45 connector
Connector type
Socket, straight
Specification
CAT 6A
Connector standard
RJ45
Type
100007525
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 21.99 / piece)
€ 23.99
-8 %
€ 21.99
incl. VAT
14-day return policy included
Highlights & Details
Telegärtner 100007525 N/A 100007525 Socket, straight Pins: 8P8C 1 pc(s)
Our service for you
Technical specifications
- Type
100007525
- Product type
RJ45 connector
- Connector type
Socket, straight
CAT 6A
- Connector standard
RJ45
- AWG max.
22
- AWG (min.)
27
- Connection
Cut & Clip
- Content
1 pc(s)
- Contact material
Spring steel 0.8 µm, gold-plated
- RoHS-compliant
Yes
- Standards
IEC 60603-7-51
IP20
- Material (details)
Die-cast zinc, CuSnZn
- Type
Straight
- Nominal current (details)
1.0 A at 50°C
22-27
- Pins
8P8C
- Mating cycles
min. 750
- Temperature range
-40°C to + 70 °C
Documents & Downloads
Datasheet
Datasheet 1179934 Telegärtner 100007525 Telegärtner 100007525 N/A 100007525 Socket, straight Pins: 8P8C 1 pc(s) 100007525 Socket, straight
User & Safety Instructions
User & Safety Instructions 1179934 Telegärtner 100007525 Telegärtner 100007525 N/A 100007525 Socket, straight Pins: 8P8C 1 pc(s) 100007525 Socket, straight
