VOLTCRAFT FM-300 Wood moisture meter Wood moisture reading range 6 up to 99 vol% Temperature reading
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 68.90 / piece)
€ 68.90
plus VAT.
Highlights & Details
VOLTCRAFT FM-300 Wood moisture meter Wood moisture reading range 6 up to 99 vol% Temperature reading
- High accuracy through integrated wood characteristics
- Humidity measurement range 6 - 99 vol-%
- Automatic temperature factor correction
- Incl. impact sensor for hard wood
Technical specifications
- Product type
Wood moisture meter
- Measurement type (details)
Invasive
- Temperature
-35 to +80 °C
- Temperature accuarcy (details)
± 2°C
- Wood moisture reading accuracy ±
1 %
Manufacturer's standards (no certificate)
- Moisture reading accuracy (misc.) ±
1 %
- Interfaces
none
- Power supply (details)
2 micro batteries (AAA)
- Dim
(W x H x D) 49 x 180 x 32 mm
- Weight
137 g
- Features
Temperature reading
- Wood moisture reading range (max.)
99 vol%
- Wood moisture reading range (min.)
6 vol%
- Moisture reading range (max.) (misc.)
99 %
- Moisture reading range (min) (misc.)
0 %
- Width
49 mm
- Height
180 mm
- Depth
32 mm
- Humidity reading accuracy
± 1 %
- Humidity reading range
6 - 99 Vol %
Documents & Downloads
Datasheet
Datasheet 100845 VOLTCRAFT FM-300 Wood moisture meter Wood moisture reading range 6 up to 99 vol% Temperature reading
User & Safety Instructions
User & Safety Instructions 100845 VOLTCRAFT FM-300 Wood moisture meter Wood moisture reading range 6 up to 99 vol% Temperature reading
User & Safety Instructions 100845 VOLTCRAFT FM-300 Wood moisture meter Wood moisture reading range 6 up to 99 vol% Temperature reading
Conformity certificate
Conformity certificate 100845 VOLTCRAFT FM-300 Wood moisture meter Wood moisture reading range 6 up to 99 vol% Temperature reading
Warranty Terms
Warranty Terms 100845 VOLTCRAFT FM-300 Wood moisture meter Wood moisture reading range 6 up to 99 vol% Temperature reading
Description
The VOLTCRAFT FM-300 Wood moisture meter Wood moisture reading range 6 up to 99 vol% Temperature reading has integrated wood characteristics, with this, a specified moisture measurement can be conducted in vol-% for most of the European wood types. Two plug gauges are used for measuring, which are held on or inserted into the material to be measured. Alternatively, measurements with automatic temperature factor correction by means of a measuring probe are possible. The measuring probe can also carry out wood temperature measurements.
A calibration tester is integrated into the protective cap. The protective cap must always be snapped on when the device is not in use.
A calibration tester is integrated into the protective cap. The protective cap must always be snapped on when the device is not in use.
Features
- Changeable penetration steel-measuring tips
- Humidity measurement with automatic temperature compensation (ATC)
- Temperature measurement
- Robust casing with sprayed rubber protection.
Scope of delivery
- 2 micro batteries (AAA)
- Impact Sensor
- Temperature sensor
- Protective cover
- 10 replacement tips
- User manual.
