Name: WAGO 2060-471/998-404-1 Spring-loaded terminal 0.75 mm² Number of pins 1 Black 1 pc(s)
Brand: WAGO
SKU: 1361156
Price: 0.43 EUR
Availability: InStock

Black plastic furniture closure, rectangular in shape with rounded edges and metal clips on the sides.

Product type

Spring-loaded terminal

4 mm

Pins per row

Number of pins

Connection

Spring-loaded terminal

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 12 Nov

486 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 7

Total (€ 0.43 / piece)

€ 0.43

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Type: 2060-471/998-404-1

Product type: Spring-loaded terminal

Features: + CAGE CLAMP®

CS: 4 mm

No. of rows: 1

Pins per row: 1

Number of pins: 1

Series: 2060

Min. stripping length: 7 mm

Stripping length (max.): 9 mm

Connection: Spring-loaded terminal
Print

Nominal current: 9 A

Cross section (flexible) (min.): 0.20 mm²

Nominal current - rounded value: 9 A

Cross section (inflexible) (min.): 0.20 mm²

Cross section (flexible) (max.): 0.75 mm²

Cross section (inflexible) (max.): 0.75 mm²

AWG (min.): 24

Connector orientation: Parallel (to the PCB)

AWG max.: 18

Contact material: Cu-alloy, tin plated

Factory colour: Black

Wire protection: Yes

Manufacturer part #: 2060-471/998-404-1

Industrial packaging: Yes

Content: 1 pc(s)

Nominal voltage: 160 V

Width: 13.10 mm

Height: 4.50 mm

Length: 3.90 mm

Type: 2060 series

Material (details): PPA-GF enclosure · Tin-plated copper contacts

Documents & Downloads

Datasheet

Datasheet 1361156 WAGO 2060-471/998-404-1 Spring-loaded terminal 0.75 mm² Number of pins 1 Black 1 pc(s)

User & Safety Instructions

User & Safety Instructions 1361156 WAGO 2060-471/998-404-1 Spring-loaded terminal 0.75 mm² Number of pins 1 Black 1 pc(s)

Description

SMD PCB terminals with CAGE CLAMP®S S-connectivity and lever. Small (height: 5.6 mm). Push-in connector for single and fine multi-strand wires with ferrules. Enables easy connecting/disconnecting of fine multi-strand cables via operating the built-in lever.
