WAGO 250-202/353-604/997-404 Spring-loaded terminal 1.50 mm² Number of pins 2 Black 160 pc(s)
Product type
Spring-loaded terminal
CS
3.50 mm
Pins per row
2
Number of pins
2
Connection
Spring-loaded terminal
Print
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 1.22 / piece)
€ 194.99
incl. VAT
14-day return policy included
Technical specifications
- KLEMMENL. 2-P.SCHWARZ, 3,5MM REFLOW
- Type
250-202/353-604/997-404
- Product type
Spring-loaded terminal
- Features
+ CAGE CLAMP®
- CS
3.50 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Series
250
- Min. stripping length
6 mm
- Stripping length (max.)
9 mm
- Connection
Spring-loaded terminal
Print
- Cross section (flexible) (min.)
0.20 mm²
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
1.50 mm²
- Cross section (inflexible) (max.)
1.50 mm²
- AWG (min.)
24
- Connector orientation
At an angle (to the PCB)
- AWG max.
16
- Factory colour
Black
- Wire protection
Yes
- Manufacturer part #
250-202/353-604/997-404
- Industrial packaging
Yes
- Content
160 pc(s)
- Nominal voltage
320 V
- Width
15.50 mm
- Height
12.00 mm
- Length
8.50 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 744849 WAGO 250-202/353-604/997-404 Spring-loaded terminal 1.50 mm² Number of pins 2 Black 160 pc(s)
User & Safety Instructions
User & Safety Instructions 744849 WAGO 250-202/353-604/997-404 Spring-loaded terminal 1.50 mm² Number of pins 2 Black 160 pc(s)
