WAGO 745-505/006-000 Spring-loaded terminal 16.00 mm² Number of pins 5 Grey 20 pc(s)
Product type
Spring-loaded terminal
CS
10 mm
Pins per row
5
Number of pins
5
Connection
Spring-loaded terminal
Print
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 20 pc(s))
Total (€ 8.25 / piece)
€ 164.99
incl. VAT
14-day return policy included
Highlights & Details
PCB terminal strip
- Content 20 pc(s)
Technical specifications
- KLEMMENLEISTE RM 10 MM GRAU 5-POLIG
- Type
745-505/006-000
- Product type
Spring-loaded terminal
- Features
+ CAGE CLAMP®
- CS
10 mm
- No. of rows
1
- Pins per row
5
- Number of pins
5
- Series
745
- Min. stripping length
12 mm
- Stripping length (max.)
13 mm
- Connection
Spring-loaded terminal
Print
- Cross section (flexible) (min.)
0.20 mm²
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
16.00 mm²
- Cross section (inflexible) (max.)
16.00 mm²
- AWG (min.)
24
- Connector orientation
At an angle (to the PCB)
- AWG max.
6
- Contact material
Cathode copper, tin plated
- Factory colour
Grey
- Wire protection
Yes
- Manufacturer part #
745-505/006-000
- Industrial packaging
Yes
- Content
20 pc(s)
- Nominal voltage
320 V
- Width
51.70 mm
- Height
33.50 mm
- Length
33.40 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 545678 WAGO 745-505/006-000 Spring-loaded terminal 16.00 mm² Number of pins 5 Grey 20 pc(s)
User & Safety Instructions
User & Safety Instructions 545678 WAGO 745-505/006-000 Spring-loaded terminal 16.00 mm² Number of pins 5 Grey 20 pc(s)
