Name: Walther Werke 64Z1110 Electricity meter (AC) Digital MID-approved: Yes 1 pc(s)
Brand: Walther Werke
SKU: 3015689
Availability: BackOrder

Black electrical socket box with two red industrial power sockets on cables. A circuit breaker is located in the centre.

Product type

Electricity meter (AC)

Display

Digital

Calibration

Calibrated

Factory colour

Black

Dim

(L x W x H) 160 x 130 x 85 mm

EAN:

Part number:

Item no:

Dispatches on Mon 9 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 479.00 / piece)

€ 479.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

CEE current meter line UniBox made of solid rubber

CEE current meter line UniBox made of solid rubber
In:32A with access: Cable with CEE plug 32A, WS-counter
Outlet: Line with CEE clutch 32A

Technical specifications

II protection rating
Protection class: IP44

Product type: Electricity meter (AC)

Display: Digital

Calibration: Calibrated

Factory colour: Black

Dim: (L x W x H) 160 x 130 x 85 mm

Operating voltage: 400 V

MID-approved: Yes

Reading type: Amperage

Nominal voltage range: 400 V (max)

Mains voltage (max.): 400 V

Width: 130 mm

Height: 85 mm

Length: 160 mm

Current (max.): 32 A

Current range: 32 A (max)

Type: 64Z1110

Effective current range: 32 A

UKCA: not relevant

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3015689 Walther Werke 64Z1110 Electricity meter (AC) Digital MID-approved: Yes 1 pc(s)

Description

Walther universal box according to IEC 61439-part 1 and 4 casing (64Z) made of unbreakable, aging, acid and alkali-resistant solid rubber.

This text is machine translated.

Features

All external metal parts are made of stainless steel
Connection: 1.5 meter connection line H07RN-F5G6 with CEE-plug 32A 5P 400V 6h
Outputs / safeguard: 1 electronic AC meter - MID certified
1.5 meter connection cable H07RN-F5G6 with CEE-coupling 32A 5P 400V 6h
Universal box according to DIN EN 61439: Individually tested, ready to connect wired, rated current 32A

Scope of delivery

CEE current meter cord UniBox
User manual.

Description

Walther universal box according to IEC 61439-part 1 and 4 casing (64Z) made of unbreakable, aging, acid and alkali-resistant solid rubber.

This text is machine translated.

Features

All external metal parts are made of stainless steel
Connection: 1.5 meter connection line H07RN-F5G6 with CEE-plug 32A 5P 400V 6h
Outputs / safeguard: 1 electronic AC meter - MID certified
1.5 meter connection cable H07RN-F5G6 with CEE-coupling 32A 5P 400V 6h
Universal box according to DIN EN 61439: Individually tested, ready to connect wired, rated current 32A
