Buy ABUS LS1020 ECOLINE IR light barrier

Two black motion sensors from ABUS, mounted side by side, for security systems in buildings.

1/3

Datasheet (PDF)

Fast track dispatch on Mon, 14 Sep

50 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 37.81 / piece)

€ 37.81

plus VAT.

Report legal concerns

ABUS LS1020 ECOLINE IR light barrier

Highlights & Details

20 m range
Water-proof (IP66)
Sabotage monitor

Technical specifications

Operating voltage: 12 - 24 V/AC/DC
Operating temperature range: -20 to +60°C
Range max. 20 m in free field
Power consumption 20 - 25 mA

Product type: IR light barrier

Features: Tamperproof

Switched outputs: Alarm output: Relay (N.O./N.C.): 1 A/ 120 V/AC · Sabotage output: N.C. contact: 1 A/ 120 V/AC

: IP66

Width: 46 mm

Height: 95 mm

Depth: 34 mm

Dim: (L x W x H) 150 cm x 46 mm x 95 mm

Content: 1 Set

Length: 150 cm

Power consumption (idle/triggered): 20 - 25 mA

Operating temperature: -20 – +60 °C

Operating voltage: 12 - 24 V AC/DC

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 751390 ABUS LS1020 ECOLINE IR light barrier

User & Safety Instructions

User & Safety Instructions 751390 ABUS LS1020 ECOLINE IR light barrier

Description

Easily installable infrared light barrier for interior and exterior! This photoelectric sensor monitors a range of up to 20 m. Smart protection against sabotage of the transmitter and receiver ensures maximum operational safety. Set these sensors in combination with our alarm systems to monitor hallways, doors, or parking lots.
