Brennenstuhl 1208380 Cable reel 40.00 m Blue PG plug
EAN:
Part number:
Item no:
Number
Total (€ 80.66 / piece)
€ 80.66
plus VAT.
Construction sites cable reel 40 m guarantor 3G1.5
Highlights & Details
- 40m cable length (H07RN-F 3G1.5) RN cable - very robust, oil-resistant and particularly suitable for professional use;Outdoor cable reel with overheating protection, control light in case of overheating and overload;Cable reel for use on construction sites according to DGUV 203-006 (former) BGI 608) and the constant application in the open;drum body made of special plastic on galvanized supporting frame with 3 safety power sockets, splash-proof, with self-closing lids;Innovative carrying handle "cablepilot" provides for a perfect cable routing and prevents the slipping of the cable when rolling or unrolling - free hands during transportation and convenient hanging
Technical specifications
- Product type
Cable reel
- Cable length
40.00 m
- Type A
PG plug
- Connector version
straight
- Type B
PG connector
- Outlets
3
- Cable colour
Blue
- Cable standard
H07RN-F 3G 1,5 mm²
- Used at
Outdoors
- Material
Plastic
- Factory colour
Blue
- Nominal input voltage
230 V
- Reel diameter
290 mm
- Weight
7.66 kg
- Protection
Overload and overheating protection
IP44
- Standards
VDE 0100 Part 704
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1216350 Brennenstuhl 1208380 Cable reel 40.00 m Blue PG plug
Description
The Garant IP44 commercial / construction site cable reel with 40m cable length in blue color from Brennenstuhl is suitable Ideal for use on construction sites and for outdoor use. It also convinces by the following features:
* Innovative carrying handle "cablepilot" for perfect cable routing. Pendulum on both sides and allows comfortable carrying and hanging
* RN cable is approved for difficult construction conditions according to VDE 0100 Part 704
* Category 2 equipment (K2 DGUV 203-005): Use for rough operation with high mechanical, physical and chemical influences
* With rotary handle for comfortable rolling up
* Protection class IP44
* Cable length 40m
* CABLE DESIGNATION H07RN-F 3G1.5
* Cable quality rubber neoprene
* Black cable color
* Drum diameter 290 mm
This text is machine translated.
* Innovative carrying handle "cablepilot" for perfect cable routing. Pendulum on both sides and allows comfortable carrying and hanging
* RN cable is approved for difficult construction conditions according to VDE 0100 Part 704
* Category 2 equipment (K2 DGUV 203-005): Use for rough operation with high mechanical, physical and chemical influences
* With rotary handle for comfortable rolling up
* Protection class IP44
* Cable length 40m
* CABLE DESIGNATION H07RN-F 3G1.5
* Cable quality rubber neoprene
* Black cable color
* Drum diameter 290 mm
This text is machine translated.
