econ connect 28AWG37GR Ribbon cable Contact spacing: 1.27 mm 37 x 0.08 mm² Grey 30.50 m
EAN:
Part number:
Item no:
Product type
Ribbon cable
CS
1.27 mm
No. of leads
37 x
Cross section (each core)
0.08 mm²
Content
30.50 m
Datasheet (PDF)
Total (1 m = € 2.64)
€ 80.66
plus VAT.
14-day return policy included
Technical specifications
- Product type
Ribbon cable
- CS
1.27 mm
- No. of leads
37 x
- Cross section (each core)
0.08 mm²
- Cross section
37 x 0.08 mm²
- Height
0.90 mm
- Factory colour
Grey
- Content
30.50 m
- Nominal voltage
300 V
- Packaged
Yes
28
- Sold per metre
No
- Insulation material
Polyvinyl chloride
- Core layout
7 x 0.125 mm
- Max. temperature range (fixed installation)
+105 °C
- Manufacturer part #
28AWG37GR
- Type
28AWG37GR
- Max. length sold by the metre
30.5 m
Documents & Downloads
Datasheet
Datasheet 1656452 econ connect 28AWG37GR Ribbon cable Contact spacing: 1.27 mm 37 x 0.08 mm² Grey 30.50 m
