Omnitronic MPVZ-250.6 PA amplifier 250 W 6-zone
EAN:
Part number:
Item no:
Number
Total (€ 457.98 / piece)
€ 457.98
plus VAT.
Highlights & Details
Omnitronic MPVZ-250.6 MIXERS
- 6-zone ELA-mono mixer amplifier
Technical specifications
- Power supply: 230 V AC, 50 Hz
- Total connected wattage 500 W
- Power output 250 W RMS
- Output type 70 V, 100 V or 4-16 Ohm
- OUTPUT CURRENT 3.6 A (70 V), 2.5 A (100 V)
- Microphone inputs 3.6 mV, 600 Ohm
- Line inputs 300 mV, 10 kOhm
- Loudspeaker outputs: Screw terminal, terminal strip
- Frequency response: 80 Hz - 16 kHz
- Distortion: 0.5% (1 kHz)
- Noise voltage spacing 85 dB (Line), 75 dB (Mic)
- Dim
(L x W x H) 9.2 x 48.3 x 38.5 cm
- Weight
12 kg
- Height
38.5 cm
- Length
9.2 cm
- Width
48.3 cm
- Interfaces
Mic 6.35 mm in
Mic input combo jack (XLR, 6.35 mm jack)
Line in
- No. of zones
6-zone
- Output type (PA amplifier)
70 V
100 V
- RMS power
250 W
- Product type
PA amplifier
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 313527 Omnitronic MPVZ-250.6 PA amplifier 250 W 6-zone
Description
6-zone ELA-mono mixer amplifier · Comfortable control for ELA speakers via 6-zone technology · 6 ELA zone outputs (100 V) each with 5-stage volume control · Master ELA speaker output (70 and 100 V) · Connection option for low-resistance loudspeakers (4-16 ohms) · 2 rear microphone inputs (6.3 mm jack, unbalanced) · 1 microphone input on the front panel (combination XLR/6.3 mm jack, unbalanced) with adjustable priority function · All microphone inputs with separate volume controls · 3 line inputs (stereo cinch) with separate volume controls · 1 line output (stereo cinch) · Chime, switchable · Treble and bass sound control for output signal · 7-fold LED-level display · Fan cooled · Protective circuits with LED display: Overvoltage, short circuit, switch-on delay · Rack installation
